Test Research Inc.
TR7500 Series User Guide–Software 513
127; - 129;
Unused
‚
130;
Low single comma quotation mark
ƒ
131;
Function sign
„
132;
Low double comma quotation mark
…
133;
Ellipses
†
134;
Dagger
‡
135;
Double dagger
ˆ
136;
Caret
‰
137;
Per mile sign
Š
138;
Capital S Hacek
‹
139;
Less-than sign
Œ
140;
Capital OE ligature
141; - 144;
Unused
‘
145;
Single beginning quotation mark
’
146;
Single ending quotation mark
“
147;
Double beginning quotation mark
”
148;
Double ending quotation mark
•
149;
Dot, middle
–
150;
En dash
—
151;
Em dash
˜
152;
Tilde
™
153;
Trademark symbol
š
154;
Small s Hacek
›
155;
Greater-than sign
œ
156;
Small oe ligature
Test Research Inc.
514 TR7700 SII User Guide–Software
157; - 158;
Unused
Ÿ
159;
Capital Y, di 熳 esis / umlaut
160;
Non-breaking Space
161;
Inverted exclamation
162;
Cent sign
163;
Pound sterling
164;
General currency sign
165;
Yen sign
166;
Broken vertical bar
167;
Section sign
168;
Di 熳 esis / Umlaut
169;
Copyright
170;
Feminine ordinal
171;
Left angle quote, guillemot left
172;
Not sign
173;
Soft hyphen
174;
Registered trademark
175;
Macron accent
176;
Degree sign
177;
Plus or minus
178;
Superscript two
179;
Superscript three
180;
Acute accent
181;
Micro sign
182;
Paragraph sign
Test Research Inc.
TR7500 Series User Guide–Software 515
7.6 不顯示[Communicate Table Wait]訊息
可在登錄檔中新增一 DWORD 參數[hidewaitboardinmsg] = 1，使得系統在等待進板時
不顯示[Communicate Table wait]訊息。
7.7 限制代料的數目
可在登錄檔中新增一 DWORD 參數[alternativecount] 來控制代料的最大數目。
7.8 發送訊號給 Hella-Samlip Magazine
在待測板檢測結果為 Fail 的時候，送訊號給 Hella-Samlip Magazine。
版本：TRAOI 3.9 Beta 2009/12/02 以後的版本
功能說明
AOI 主程式檢測出待測板狀態為 FAIL 的時候，依序送給韓國 Halle-Samlip Magazine
下面三個訊號
N.G PCB Out Signal(R702) On (PCPLC)
%01#WCSR07021**\r W 表示 Write，1 表示 ON
讀取剛剛寫入的值作確認
%01#RCSR0702**\r R 表示 Read，PLC 應該會回傳 %01#RC120，
1 表示 ON
N.G PCB Information Data Set (DT10000 ~10099) (PCPLC)
%01WDD1000010003YYYYMMDDHHMMSS99**\r
W 表示 Write, 10000 / 10003 表示寫入 PLC 暫存器(10000~10003),
YYYYMMDDHHMMSS 表示待測板檢測時間
讀取剛剛寫入的值作確認
%01RDD1000010003**\r R 表示 Read
N.G PCB Out Finish (R702) Off (PCPLC)
%01#WCSR07020**\r W 表示 Write， 0 表示 ON
