4OM-1610

3-130

3. Error IDs and Remedial Procedures : Chap.3

1011-002

Error ID Error Name, Description, Cause, and Remedy

601305 Noz stocker offset teaching

Error of NL-axis movement

-----

601306 Noz stocker offset teaching

Error of L-axis movement

-----

601307 Noz stocker offset teaching

Error of HL/NL/L-axis movement

-----

601308 Noz stocker offset teaching

Nozzle stocker is not clamped

-----

601309 Noz stocker offset teaching

Error of Lighting On of P.C.B. Recognition Camera

-----

60130a Noz stocker offset teaching

Timeout of Lighting On of P.C.B. Recognition Camera

-----

60130b Noz stocker offset teaching

Error of Lighting Off of P.C.B. Recognition Camera

-----

60130c Noz stocker offset teaching

Time-out of Lighting Off of P.C.B. Recognition Camera

-----

60130d Noz stocker offset teaching

Error of image capture of Nozzle Stocker Mark

-----

60130e Noz stocker offset teaching

Time-out of image capture of Nozzle Stocker Mark

-----

60130f Noz stocker offset teaching

Error of Recognition Performance of Nozzle Stocker Mark

-----

601310 Noz stocker offset teaching

Time-out of Recognition Performance of Nozzle Stocker Mark

-----

601311 Noz stocker offset teaching

Error of output-movement of Nozzle Stocker

-----

601401 T

eaching

Comp.Recog.CameraMagnicationTeach

Time-out of communication with recognition.

Is there Network with Recognition? Please check.

601402 Teaching

Comp.Recog.CameraMagnicationTeach

Error of Recognition Command response

-----

4OM-1610

3-131

3. Error IDs and Remedial Procedures : Chap.3

1011-002

Error ID Error Name, Description, Cause, and Remedy

601a01 Linear measure sensor correction re-teach

The linear measure reading is abnormal.

Pleaseconrm

whetherthenozzlehasadheredtotheposition.

601a02 Linear measure sensor correction re-teach

Offset correction can not be completed. Please use the big nozzle(HA05) teach

again and adjust the light & receive optical Axis

-----

601a03 Linear measure sensor correction re-teach

Nozzle can not be detected.

-----

601a04 Linear measure sensor correction re-teach

Line Sensor Control is abnormal.

-----

601a05 Linear measure sensor correction re-teach

Offset correction can not be completed. Please use the big nozzle(HA05) teach

again and adjust the light & receive optical Axis(All samples are E/R-Err7)

-----

601a06 Linear measure sensor correction re-teach

Offset correction can not be completed. Please use the big nozzle(HA05) teach

again and adjust the light & receive optical Axis(All samples are E/NR-Err8)

Offset correction can not be completed. Please use the big nozzle(HA05) teach

-----

601a07 Linear measure sensor correction re-teach

again and adjust the light & receive optical Axis(Edge detect error-Err9)

-----

601a08 Linear measure sensor correction re-teach

Offset correction can not be completed. Please use the big nozzle(HA05) teach

again

and

adjustthelight&receiveopticalAxis(Insufcientsamples-Err10)

-----

601a09 Linear measure sensor correction re-teach

Offset correction can not be completed. Please use the big nozzle(HA05) teach

againand

adjustthelight&receiveopticalAxis(Insufcientcorrectingsamples-

Err14)

-----

601a0a Linear measure sensor correction re-teach

Offset correction can not be completed. Please use the big nozzle(HA05) teach

again and adjust the light & receive optical Axis(Fail to create correction-Err15)

-----

601a0b Linear measure sensor correction re-teach

Offset correction can not be completed. Please use the big nozzle(HA05) teach

again and adjust the light & receive optical Axis(Accuracy check NG-Err16)

-----

601a0c Linear measure sensor correction re-teach

Offset correction can not be completed. Please use the big nozzle(HA05) teach

again and adjust the light & receive optical Axis(Fail to save-Err17)

-----

4OM-1610

3-132

3. Error IDs and Remedial Procedures : Chap.3

1011-002

Error ID Error Name, Description, Cause, and Remedy

601a0d Linear measure sensor correction re-teach

The measurement value of the nozzle is not within 0.2mm to 0.6mm.

Adjust the height of the linear measure sensor otherwise, replace it.

601a0e Linear measure sensor correction re-teach

The linear measure control has an error.(err2, err3)

All E/NR Error. There is a possibility that Light Emitter or Receiver is broken.

601a0f Linear measure sensor correction re-teach

The linear measure control has an error.(err1)

Could be P.C.B. Error

601a10 Linear measure sensor correction re-teach

The linear measure control has an error.(err4)

A quantity of light emitter is dropping. There is a possibility of Light Emitter broken.

601a11 Linear measure sensor correction re-teach

No strobe response

Please

conrm

thewiringofHLS.Either,conrmP.C.B.address.

601f01 NL Axis offset teach

Error before Line Sensor measurement began

-----

601f02 NL Axis offset teach

ODD Noz is placed on Head, or error is detected during linear measure sensor.

-----

601f03 NL Axis offset teach

Error of NS-axis movement

-----

601f04 NL Axis offset teach

Error of DD-axis movement

-----

601f05 NL Axis offset teach

Error of NL-axis movement

-----

601f06 NL Axis offset teach

Error of DD/NS-axis movement

-----

601f07 NL Axis offset teach

Time-out when Line Sensor measurement began

-----

601f08 NL Axis offset teach

Read Time-out of Line Sensor measurement

-----

601f09 NL Axis offset teach

Time-out of NL-axis movement

-----

601f0a NL Axis offset teach

Time-out of DD/NS-axis movement

-----
