1.5

1.5 Abbreviations

Abbreviations

Abbreviations Description

BB, BB1, BB2 Placement area, Placement area 1, Placement area 2

CO Component

C&P Collect&Place

C&P12, CP12 Collect&Place head with 12 segments

C&P20, CP20 Collect&Place head with 20 segments

C&P6, CP6 Collect&Place head with 6 segments

CPP Collect&Pick&Place head

CPx Collective term for CPP, CP20, CP12 and/or CP6

ESD Electrostatic sensitive device

EMC Electromagnetic compatibility

FHE Fast Head Exchange

PCB Board

P&P Pick&Place

SCS Single Core Solution

TH TwinHead

VS Vision system type

ID Intermediate distributor

ID1, ID2 Intermediate distributor 1, intermediate distributor 2

1 Introduction

1.5 Abbreviations 1.3.7 SIPLACE on the World Wide Web (WWW)

14 Service Manual SIPLACE C&P20, C&P20A, C&P20M

2 Overview of the Modules

2.1.1 Differentiation of the C&P20 heads 2.1 C&P20, C&P20A and C&P20M head

Service Manual SIPLACE C&P20, C&P20A, C&P20M 15

2 Overview of the Modules

Overview of the Modules

2.1

2.1 C&P20, C&P20A and C&P20M head

C&P20, C&P20A and C&P20M head

2.1.1

2.1.1 Differentiation of the C&P20 heads

Differentiation of the C&P20 heads

Differenc es between CP 20/A/M

The C&P20A differs from the C&P20 in the following issues:

▪ New E/D transformer

▪ Improved linear guide rails at the segments

▪ Driver bearing

▪ Modified Z-axis (also used in C&P20 later on)

▪ Hoses

▪ FHE components

The C&P20M differs from the C&P20A in the following issue:

▪ Incremental encoder of the star motor

C&P20A

1. Star motor

2. Pressure control valve

3. DP drives (20 x)

4. Star with 20 nozzles

5. Component Camera

6. Intermediate distributor board

NOTICE

C&P20, C&P20A, C&P20M

The instructions apply in principle to all C&P20, C&P20A and C&P20M heads.

Any differences will be explicitly indicated.

► The different heads can be recognized according to the labeled stickers.
