3 2 T op Cover (Ceiling) Cover KMB-1712 2 5 5 3 3 4 7 4 5 5 4 6 8 1 6 8 No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 KLF-M1306-A1 COVER6 ASSY . 1 2 KLF-M1306-02 COVER 6 1 3 KLF-M130H-02 COVER,F A…
2
2
Top Cover (Left side)
Cover
KMB-1712
46
26
32
43
35
15
41
16
10
32
17
31
39
27
32
45
18
5
25
28
8
23
19
21
41
3
38
32
44
34
47
34
42
36
14
32
32
34
44
37
6
44
13
41
34
32
32
12
41
14
33
7
32
9
9
45
18
44
34
23
46
32
2
32
32
20
22
38
8
30
17
31
15
41
6
32
1
32
4
32
36
11
24
29
31
40
43
35
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KMB-M1301-00 COVER 1 1
2 KMB-M1302-00 COVER 2 1
3 KLF-M1321-00 BRKT,21 1
4 KLF-M1387-01 BRKT.,PAT LIGHT 1
5 KMB-M130B-00 COVER,SW 1
6 KMB-M13A4-00 COVER A4 2
7 KMB-M13A5-00 COVER A5 1
8 KMB-M131A-00 COVER A LR 2
9 KMB-M131B-00 COVER B LR 2
10 KLF-M1318-00 COVER 18 1
11 KMB-M1372-00 COVER 72 1
12 KLF-M9133-01 PLATE,DUCT 1
13 KLF-M1332-01 BRACKET 2 1
14 KLF-M1333-02 BRKT. 1 2
15 KMB-M1336-00 RAIL,COVER 2
16 KLF-M133A-01 BRKT,LCD UNIT 1
17 KMB-M26FM-00 FLAME,1-1 2
18 KV5-M1130-00 CATCH MG. 2
19 KLF-M13F1-01 COVER,CE R 1
19-1 KMB-M13F1-A0 COVER,CE R SUB ASSY. 1 OK MP60118-2017/7/11
20 KLF-M13F2-01 COVER,CE L 1
20-1 KMB-M13F2-A0 COVER,CE L SUB ASSY. 1 OK MP60118-2017/7/11
21 KLF-M13F3-00 GUIDE,FES. R 1
22 KLF-M13F4-00 GUIDE,FES. L 1
23 KLF-M13F6-00 BAMPER 2
24 KLF-M133D-00 SEAL,BLIND 2
25 KMB-M13D6-00 SEAL 1(YSM40R) 1
26 90K41-001250 LABEL,WARNING 2
27 90K41-001260 LABEL,WARNING 1
28 KH1-M13A9-00 BUSH 1
29 90990-23J008 GROMMET
1
30 90990-23J006 GROMMET 1
31 90990-01J074 BOLT HEX,SOCKET HEAD 22
32 90990-12J001 SCREW,BIN. HEAD W/W 67
33 90990-12J004 SCREW, BIN. HEAD W/W 22
34 90172-00J040 WASHER,EXTL.TOOTHED 16
35 90172-00J050 WASHER,EXTL.TOOTHED 2
36 91312-04005 BOLT,HEX.SOCKET HEAD 8
37 91312-04010 BOLT,HEX.SOCKET HEAD 4
38 91312-04020 BOLT,HEX.SOCKET HEAD 4
39 91312-04035 BOLT,HEX.SOCKET HEAD 3
40 91312-05006 BOLT,HEX.SOCKET HEAD 1
41 91312-05008 BOLT,HEX.SOCKET HEAD 6
42 92902-04200 WASHER,PLAIN 4
43 92902-05200 WASHER, PLAIN 2
44 95702-04500 NUT FLANGE 14
45 98902-03005 SCREW_BINDING HEAD 4
46 98902-03010 SCREW, BINDING HEAD 2
47 KMB-M1307-00 COVER 1-2 1 No DIP-ST
3
2
Top Cover (Ceiling)
Cover
KMB-1712
2
5
5
3
3
4
7
4
5
5
4
6
8
1
6
8
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M1306-A1 COVER6 ASSY. 1
2 KLF-M1306-02 COVER 6 1
3 KLF-M130H-02 COVER,FAN 2
4 90990-12J001 SCREW,BIN. HEAD W/W 16
5 98502-04050 SCREW PAN HEAD (+) 16
6 KLF-M1329-01 COVER 29 2
7 KLF-M130J-00 FILTER,TOP COVER FAN 2
8 98902-03005 SCREW_BINDING HEAD 8
4
2
Door
Cover
KMB-1712
16
13
29
10
26
25
21
25
34
23
34
25
21
25
14
34
26
4
36
22
35
18
19
24
31
26
22
17
28
11
27
42
43
32
20
22
36
17
28
36
26
25
21
25
34
12
5
6
44
9
7
26
15
26
30
33
37
7
40
3
29
34
25
21
25
26
10
A
A
23
1
45
38
39
45
39
45
38
1
45
33
26
20
30
15
2
14
35
37
34
8
41
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KMB-M1309-A0 COVER 9 ASSY. 2
2 KLF-M1309-01 COVER 9-1 1
3 KMB-M130A-00 COVER 9-2 1
4 KMB-M130K-00 BRKT. 1,COVER 9 1
5 KMB-M130L-00 BRKT. 2,COVER 9 1
6 KMB-M130R-00 WINDOW,COVER 9 1
7 KMB-M130S-00 PLATE,WINDOW 1 2
8 KMB-M130T-00 PLATE,WINDOW 2 1
9 KLF-M1347-00 COVER 9-4 1
10 KLF-M1345-00 PLATE,LINK 2
11 KLF-M1324-00 KNOB 1
12 KLF-M134A-00 BRKT. NUT L 1
13 KLF-M134B-00 BRKT. NUT R 1
14 KLF-M1328-00 BRACKET, GAS DAMPER 2
15 KGS-M1348-00 GAS,SPRING 2
16 K46-M1374-12 HINGE 2 3
17 KLF-M1374-00 HINGE 2
18 KLF-M1373-00 BRACKET 1, SCHMEASAL 1
19 KL0-M1374-00 PLATE 1, SCHMEASAL 1
20 KGS-M1360-00 BOLT 4
21 KHT-M1346-00 BUSH 4
22 90172-00J040 WASHER,EXTL.TOOTHED 15
23 90990-12J002 SCREW BIN.HEAD W/W 18
24 90990-28J003 WASHER, PLAIN 2
25 90990-28J166 WASHER,PLAIN 8
26 90990-31J006 BOLT, SHOULDER 8
27 90990-46J001 BOLT THIN HEAD 4
28 91312-04005 BOLT,HEX.SOCKET HEAD 12
29 91312-05008 BOLT,HEX.SOCKET HEAD 4
30 91312-05012 BOLT HEX.SOCKET HEAD 4
31 91312-06010 BOLT,HEX.SOCKET HEAD 2
32 92902-04200 WASHER,PLAIN
2
33 92902-05200 WASHER, PLAIN 4
34 92902-06200 WASHER,PLAIN 6
35 95307-06600 NUT, HEXAGON 2
36 95702-04500 NUT FLANGE 15
37 97602-04306 SCREW,BIN.HEAD W/W. 8
38 KLF-M26F4-00 PLATE 4 2
39 KLF-M26F5-00 PLATE 5 2
40 KKX-M13D7-00 SEAL 2(YAMAHA) 2
41 KMB-M13D8-00 LABEL(Z:TAR) 2
42 90K41-001250 LABEL,WARNING 2
43 90K41-001420 LABEL,WARNING 2
44 KLF-M1392-00 LABEL,WARNING 2
45 91312-05008 BOLT,HEX.SOCKET HEAD 18
