5 4 Y -axis Frame / Cable / Scale Moving-axis KMB-1712 18 36 22 22 22 22 49 49 36 21 21 21 21 45 45 45 45 3 1 2 25 25 25 40 40 26 26 25 23 23 3 3 7 43 5 5 4 4 12 34 50 13 51 10 11 14 9 50 50 51 13 10 35 38 38 50 14 8 6 6…
4
4
Y-axis / Motor
Moving-axis
KMB-1712
24
22
24
34
34
34
23
3
31
31
7
6
6
6
5
6
7
4
9
9
9
9
20
20
20
20
21
21
21
21
31
10
10
10
10
31
31
31
29
35
35
28
28
36
29
36
11
11
11
11
1
1
31
38
38
38
38
38
38
2
2
8
8
8
8
8
8
31
31
31
3
31
31
31
31
31
14
15
15
19
19
17
18
33
16
16
27
27
12
39
30
32
30
39
37
37
37
4
5
23
23
23
34
34
34
34
34
26
26
26
26
25
24
24
24
24
25
11
11
11
13
13
14
15
15
19
19
17
18
33
16
16
27
27
12
39
30
32
30
11
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M2610-03 GUIDE,30 Y AXIS 2
2 KLF-M2611-00 GUIDE,25 Y AXIS 2
2-1 KMB-M2611-00 GUIDE,25 Y AXIS 2 Roller type OK MNX0039-2016/11/10
2-2 KMB-M2611-A0 GUIDE,25 Y AXIS SET 2 Roller type+28+SHIM (Spare) OK H024584-2017/9/19
3 KLF-M261A-A0 PILOT VALVE A ASSY 2
4 KLF-M261A-00 KLF-M261A-000 2
5 KLF-M2620-00 PLATE,VALVE.Y 2
6 $TSH4-01 JOINT 4
7 $TL4-01M JOINT 2
8 KLF-M2624-00 COVER,GUIDE Y 6
9 KLF-M2629-00 PLATE SW.Y 4
10 KMB-M2658-00 BRKT.,S FIX Y AXIS 4
11 KLF-M266D-00 JOINT 4
11-1 $TSH4-M6M JOINT 4 OK MP00003-2017/10/10
12 KMB-M2679-00 BRKT.,ACCUMLATOR 2
13 KMB-M26S0-A0 ACCUMLATOR 1 ASSY. 2
14 KMB-M26S0-B0 ACCUMLATOR 2 ASSY. 2
15 KLF-M26S1-01 ACCUMLATOR 4
16 KLF-M223J-00 JOINT 12
17 KMB-M26S3-00 DAMPER,1 2
18 90990-41J168 COLLAR 4
19 KMB-M26S4-00 SPONGE 4
20 KLF-M653G-00 SENSOR Y ORG ASSY 4
21 KLF-M653H-00 SENSOR Y OT ASSY 4
22 KMB-M26C0-00 LINEAR MOTOR ASSY. 1
23 KLF-M26C0-A0 MOTOR,Y AXIS 4
24 KMB-M26C0-B0 SHORT STATOR ASSY. 6
25 KMB-M26C0-C0 LONG STATOR ASSY. 2
26 KLF-M26C8-00 PLATE 4
27 $SL10-02 JOINT
12
28 90K81-200002 CAP 62
29 90K81-200009 CAP C8 48
30 91312-04006 BOLT HEX.SOCKET HEAD 4 M4X6
31 91312-04008 BOLT HEX.SOCKET HEAD 20 M4X8
32 91312-04010 BOLT HEX.SOCKET HEAD 10 M4X10
33 91312-04012 BOLT,HEX.SOCKET HEAD 4 M4X12
34 91312-06018 BOLT HEX.SOCKET HEAD 100 M6X18
35 91312-06020 BOLT HEX.SOCKET HEAD 62 M6X20
36 91312-08025 BOLT HEX.SOCKET HEAD 48 M8X25
37 97602-03308 SCREW,PAN HEAD W/W 16
38 98902-04008 SCREW, BINDING HEAD 36
39 92902-04200 WASHER, PLAIN 8
5
4
Y-axis Frame / Cable / Scale
Moving-axis
KMB-1712
18
36
22
22
22
22
49
49
36
21
21
21
21
45
45
45
45
3
1
2
25
25
25
40
40
26
26
25
23
23
3
3
7
43
5
5
4
4
12
34
50
13
51
10
11
14
9
50
50
51
13
10
35
38
38
50
14
8
6
6
43
3
47
47
44
49
47
44
44
49
47
44
32
31
39
39
36
39
36
36
39
36
27
27
27
27
28
28
28
28
33
33
37
37
37
33
33
37
24
26
26
17
16
16
15
17
17
15
17
24
19
19
19
19
30
30
29
29
36
36
41
41
41
18
36
41
42
48
48
46
46
42
48
48
46
20
46
36
36
36
20
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M2605-A0 STAY,SCALE L ASSY. 1
2 KLF-M2605-B0 STAY,SCALE R ASSY. 1
3 KMB-M2617-A1 CABLE,Y AXIS ASSY 4
4 KMB-M260B-01 TAPE,1 DUCT Y 1
5 KMB-M260C-01 TAPE,2 DUCT Y 1
6 KMB-M260D-01 TAPE,3 DUCT Y 1
7 KMB-M2617-01 CABLE DUCT,Y 1
8 KMB-M2618-01 BRKT.,DUCT Y 1
9 KMB-M2620-01 PLATE,DUCT Y 1
10 KMB-M2666-01 PLATE,NUT 2
11 KMB-M2668-01 BRACKET,1 HARNESS 1
12 KMB-M2669-01 BRACKET,2 HARNESS 1
13 $CTAM1 ANCHOR MOUNT 10
14 $NK-2N NYLON CLIP 10
15 KLF-M261B-00 BRKT.,1 FIXED MARK 2
16 KLF-M261C-00 BRKT.,2 FIXED MARK 2
17 KLF-M261D-00 SUPER L/H SCREW 8
18 KMB-M26F1-01 FRAME,1 2
19 KMB-M26F2-01 COVER,FRAME 1 4
20 KMB-M26F3-00 FRAME,3 2
21 KLF-M26F8-00 PLATE,DUCT SHEET 4
22 KLF-M26FD-00 BRACKET,DUCT Y 4
23 KLF-M26T1-00 TAPE,Y LINEAR SCALE 2
24 KLF-M26T2-00 CLAMP,SCALE 2
25 KLF-M26T4-02 HEAD,LINEAR SCALE Y 4
26 KLF-M26T6-00 REF.MARK 4
27 KV7-M2651-00 DAMPER, STOPPER 4
28 KHW-M2654-00 PLATE,DAMPER 4
29 $AUS10 JOINT 12
30 $UY8 JOINT 3
31 $AUY10 JOINT 1
32 $UYD10-8 JOINT
2
33 90990-41J180 COLLAR 8
34 90990-01J011 BOLT, HEX. SOCKET HEAD 2
35 90990-01J032 BOLT, HEX. SOCKET HEAD 2
36 91312-04006 BOLT HEX.SOCKET HEAD 36 M4X6
37 91312-04008 BOLT HEX.SOCKET HEAD 8 M4X8
38 91312-04010 BOLT HEX.SOCKET HEAD 4 M4X10
39 91312-04012 BOLT HEX.SOCKET HEAD 12 M4X12
40 91312-04016 BOLT HEX.SOCKET HEAD 36 M4X16
41 91312-05006 BOLT HEX.SOCKET HEAD 16 M5X6
42 91312-05010 BOLT HEX.SOCKET HEAD 16 M5X10
43 91312-05014 BOLT HEX.SOCKET HEAD 8 M5X14
44 91312-06014 BOLT HEX.SOCKET HEAD 16 M6X14
45 98902-04005 SCREW, BINDING HEAD 23
46 92902-05600 WASHER, PLAIN 8
47 92902-06600 WASHER, PLAIN 16
48 90172-00J050 WASHER, EXTL. TOOTHED 8
49 90172-00J060 WASHER, EXTL. TOOTHED 16
50 97602-04308 SCREW,PAN HEAD W/W 20
51 98902-03006 SCREW, BINDING HEAD 4
1
5
Head (MU)
Head
KMB-1712
17
25
7
20
20
12
4
29
30
15
15
9
19
28
24
24
21
23
23
18
10
2
1
26
19
19
19
22
6
8
11
27
16
5
20
3
28
13
14
31
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KLF-M71K0-00 Z AXIS ASSY.1 2
2 KLF-M71L0-00 Z AXIS ASSY.2 2
3 KLF-M715A-A2 VALVE,ASSY. 1
4 KLF-M7150-B0 VALVE,PRESS. 1
5 KLF-M7109-00 BASE,VALVE 1
6 KLF-M71C1-00 COVER,CABLE 1
7 KLF-M71C4-00 BRACKET,CONNECTOR 1
8 KLF-M71C8-00 BRACKET,COVER 1
9 KLF-M71C9-01 COVER,HEAD 1
10 KLF-M71CD-00 CLAMP,HARNESS 2
11 KLF-M71Y0-00 LABEL,HEAD SERIAL 2
12 KLF-M7152-00 VALVE, SPARE 1 Spare
13 KLF-M7153-00 VALVE 1 Spare
14 KLF-M7154-00 JOINT 1 Spare
15 90990-01J058 BOLT,HEX.SOCKET HEAD 6
16 90990-46J007 BOLT,THIN HEAD 4
17 97602-04306 SCREW,BIN.HEAD W/W. 4
18 98902-03004 SCREW BINDING HEAD 6
19 91312-04005 BOLT HEX.SOCKET HEAD 8 M4X5
20 91312-04012 BOLT,HEX.SOCKET HEAD 8 M4X12
21 91312-04016 BOLT,HEX.SOCKET HEAD 4 M4X16
22 91312-04025 BOLT HEX.SOCKET HEAD 4 M4X25
23 91312-04045 BOLT HEX.SOCKET HEAD 16 M4X45
24 91312-05012 BOLT HEX.SOCKET HEAD 8 M5X12
25 $NK-4N NYLON CLIP 4
26 KLF-M712A-00 TUBE(TUS0425N) 6
27 KLF-M712B-00 TUBE(TUS0425N) 4
28 KLF-M712C-00 TUBE(TUS0425N) 10
29 KLF-M712D-00 TUBE(TUS0425N) 4
30 $UB0850-R
URETHANE TUBE 2 (200mm)
31 KLF-M7153-10 VALVE 1 Spare MK10136-2013/2/1
