Check Code Display Section A Display Section B

030401 Operation Please input barcode data by manual input screen.

Requirement

030402 Operation Please check the operation in "pass" mode.

Requirement

030403 Operation X/Y chute P.C.B. detection is one side mode.

Requirement

030404 Operation Please exit P.E.C. manual adjustment mode.

Requirement (Click right and left button)

030405 Operation Please wait for a while.

Requirement (Now Machine is initializing.)

030406 Operation Nozzle level mismatch with component thickness (t). Collect

Requirement component and attach one again.

030407 Operation Recognition fail. Check data and component position.

Requirement

030408 Operation The current program changed. Please perform setup operation.

Requirement

030409 Operation Please check final mount step condition for eye adjustment.

Requirement This mount position was detected outside of the possible

range.(PEC position)

030410 Operation This teach point was detected outside of the possible range.

Requirement

030411 Operation This origin point was detected outside of the possible range.

Requirement (PEC position)

030412 Operation This destinate step was detected outside of the possible range.

Requirement (PEC position)

050101 No Current Select the current program.

050102 No Current Incorrect data found within internal current program. Please retry

program change.

050201 Setup Check Set up X/Y chute width.

050202 Setup Check Set up L conveyor width.

050203 Setup Check Set up R conveyor width.

050204 Setup Check Set up conveyor width.

050205 Setup Check Move the X/Y chute up.

050206 Setup Check Set up PCB support pins up/down.

050207 Setup Check Set up PCB locate lever.

050208 Setup Check Please input transfer stroke data.

050209 Setup Check Please input Zero Position.

05020a Setup Check Please input PCB locate lever size.

05020b Setup Check Set up X/Y chute width for Y-clamp action.

05020c Setup Check Please Transfer and Set P.C.B. on the X/Y table. (X/Y table on

P.C.B. is non clamp condition.)

0511-002 2-7 AIL01ETRP

1.2 "CHECK" Windows

Check Code Display Section A Display Section B

05020d Setup Check The P.C.B.-Clamp was detected Vacuum Leak. Please check the

P.C.B. -Clamp condition or Vacuum Leak Setting level.

05020e Setup Check "X-Clamp Pressure set value. ( "0" value is not active)."

050301 Recognition Data Please check recognition nozzle data and carry out data trans

Missing again.

050302 Recognition Data Please check comp recog lighting data and carry out data trans

Missing again.

050303 Recognition Data Please check recog camera mag data and carry out data trans

Missing again.

050304 Recognition Data Please check recog camera offset data and carry out data trans

Missing again.

050305 Recognition Data Please check recog camera gain level data and carry out data

Missing trans again.

050306 Recognition Data Please check recog nozzle gain level data and carry out data

Missing trans again.

050307 Recognition Data Please check comp recog data and carry out data trans again.

Missing

050308 Recognition Data Please check recog execution mode data and carry out data trans

Missing again.

070101 Front Safety Door Close the safety door and zero all device with the [ZERO] button.

070201 Rotary Wheel Pull on the rotary wheel handle.

070301 Front Area Sensor Remove foreign substance.

070401 Unavailable Data Input available feeder No. in current program.

070402 Unavailable Data Input available placement step in current program.

090101 Disengaged PCB Set P.C.B. on the X/Y table.

090201 Chute Lower Limit Move the X/Y chute down.

090301 Feeder Carriage Separate both feeder carriages and zero all devices with the

Collision [ZERO] button.

090401 Cam Phase Check the cam positioner.

090402 Cam Phase Re-adjust or repair the cam shaft if necessary.

090501 Out Of Limit Zero all device with the [ZERO] button.

090502 Out Of Limit Feeder carriage #1 limit error has been detected.Moving the feeder

carriage #1.Check the feeder carriage #1 limit sensor .

090503 Out Of Limit Feeder carriage #2 limit error has been detected.Moving the feeder

carriage #2.Check the feeder carriage #2 limit sensor .

1.2 "CHECK" Windows

0511-002 2-8 AIL01ETRP

Check Code Display Section A Display Section B

090601 Linear Measure Press the [POWER OFF] button once and press the [POWER

Alarm ON] button.

090701 Out Of Feeder Axis Zero all device in manual mode or with the [ZERO] button.

Stationary Position

090702 Out Of Feeder Axis Check the feeder.

Stationary Position

090703 Out Of Feeder Axis Check feeder motor 1 & 2.

Stationary Position

090704 Out Of Feeder Axis Please check area around feeder carriage located at its home

Stationary Position position #1.

090705 Out Of Feeder Axis Please check area around feeder carriage located at its home

Stationary Position position #2.

090801 Rotary Turret Origin Adjust rotary turret angle to 0° or 360°.

090901 Furnace Signal Check the furnace signal.

090a01 Oil Cooler Alarm Check the cooling oil.

090b01 Cooling FAN Alarm Check the cooling FAN.

091001 Recognition Ready Wait until recognition unit is ready to work.

0b0107 Feeder Carriage Not Still have feeder carriage interlock. Restore Load Power again.

Ready Switch

0b0111 Feeder Carriage Not Press the [F1 READY] button to set feeder carriage #1 in ready

Ready Switch mode.

0b0116 Feeder Carriage Not Press the [F2 READY] button to set feeder carriage #2 in ready

Ready Switch mode.

0b0211 Operation Area Feeder Close saf. guard at crg. home pos. 1.

Axis Safety Guard

0b0216 Operation Area Feeder Close saf. guard at crg. home pos. 2.

Axis Safety Guard

0b0301 Operation Area Feeder Open saf. guard at crg. home pos.

Axis Safety Guard

0d0101 Out Of Origin Zero X/Y chute width.

0d0102 Out Of Origin Zero L conveyor width.

0d0103 Out Of Origin Zero R conveyor width.

0d0104 Out Of Origin Zero conveyor width.

0d0105 Out Of Origin Zero all devices with the [ZERO] button.

0d0106 Out Of Origin Zero PCB support pins up/down.

0d0107 Out Of Origin Zero PCB locate lever.

0d0108 Out Of Origin Zero X/Y table axis.

0d0109 Out Of Origin Zero camera X/Y axis.

0d0201 Feeder Axis Servo Restore Load Power again, or Check F1saf.guard if open/close

Down

0d0202 Feeder Axis Servo Restore Load Power again, or Check F2saf.guard if open/close

Down

0511-002 2-9 AIL01ETRP
