1.3 Machine lnformation
0511-002 2-12 AIL01ETRP
1.3.2 List of Check Messages
Table 4B2
Check Code Display Section A Display Section B
800101 Auto Noz. Bypass Nozzle down error(L)
Started
800102 Auto Noz. Bypass Nozzle down error(H)
Started
800103 Auto Noz. Bypass Handling err-cont:
Started
800104 Auto Noz. Bypass Decreasing of comp.handling rate
Started
800105 Auto Noz. Bypass Selected nozzle position error
Started
800106 Auto Noz. Bypass Nozzle Posture Detection
Started
(Contents) The nozzle was automatically bypassed.
(Description) Follow the described instructions to reset the machine to its normal condi-
tion.
Refer to "3.3 "Head/Noz. Bypass" Tab" in "Section 5" (Vol. 2: Operation
(Supervisor))" for details.
800201 Auto Head Bypass Communication error.
Started
800202 Auto Head Bypass Head origin error.
Started
800203 Auto Head Bypass Overtime head origin error. Set ct:3(fixed value)
Started
800204 Auto Head Bypass Unselected nozzle drop. Set ct:2(fixed value)
Started
800205 Auto Head Bypass CAM position.
Started
800206 Auto Head Bypass Origin Return Action.
Started
800207 Auto Head Bypass Motor Out of Control
Started
800208 Auto Head Bypass Current OverLoad.
Started
800209 Auto Head Bypass Motor not connected.
Started
(Contents) The nozzle was automatically bypassed.
(Description) Follow the described instructions to reset the machine to its normal condi-
tion.
Refer to "3.3 "Head/Noz. Bypass" Tab" in "Section 5" (Vol. 2: Operation
(Supervisor))" for details.
Check Code Display Section A Display Section B
800210 Auto Head Bypass Solenoid not connected.
Started
800211 Auto Head Bypass Power line warning.
Started
800212 Auto Head Bypass Power line error.
Started
800213 Auto Head Bypass Driver temperature warning.
Started
800214 Auto Head Bypass Driver temperature error.
Started
800215 Auto Head Bypass EEPROM error.
Started
800216 Auto Head Bypass Sensor error.
Started
800217 Auto Head Bypass Head cam position return action not complete.(Not CAM ORI-
Started GIN position)
800218 Auto Head Bypass Head Driver communication time out.
Started
800219 Auto Head Bypass Nozzle change action not complete.(Not CAM ORIGIN position)
Started
800220 Auto Head Bypass Cam position self-check warning.
Started
(Contents) The nozzle was automatically bypassed.
(Description) Follow the described instructions to reset the machine to its normal condi-
tion.
Refer to "3.3 "Head/Noz. Bypass" Tab" in "Section 5" (Vol. 2: Operation
(Supervisor))" for details.
800301 Warning: Decreasing Nozzle message rate :
of Comp. Hdlg. Rate
(For Noz.)
800401 Warning: Decreasing Feeder message rate :
of Comp. Hdlg. Rate
(For Fdr.)
(Contents) The component pick-up rate has deteriorated.
(Description) Check the related nozzle or feeder and take necessary measures to
improve the pick-up rate.
1.3 Machine lnformation
0305-001 2-13 AIL01ETRP
1.3 Machine lnformation
0511-002 2-14 AIL01ETRP
Check Code Display Section A Display Section B
800501 Alternated Feeder Comp. Missing(sensor)
Carriage Axis
800502 Alternated Feeder Comp. Vertical(sensor)
Carriage Axis
800503 Alternated Feeder Comp. Missing(recog.)
Carriage Axis
800504 Alternated Feeder Comp. Recog. Error
Carriage Axis
800505 Alternated Feeder Shortage of component
Carriage Axis
800506 Alternated Feeder Start recovery mode.
Carriage Axis
800507 Alternated Feeder Comp. Thickness(sensor)
Carriage Axis
800508 Alternated Feeder Comp. Pickup Diff.(recog.)
Carriage Axis
800509 Alternated Feeder Comp. Reverse(recog.)
Carriage Axis
(Contents) The unit alternate function has worked.
(Description) Check the related feeder and take necessary measures such
as component replenishment.
800601 Alternated Feeder Comp. Missing(sensor)
800602 Alternated Feeder Comp. Vertical(sensor)
800603 Alternated Feeder Comp. Missing(recog.)
800604 Alternated Feeder Comp. Recog. Error
800605 Alternated Feeder Shortage of component
800606 Alternated Feeder Start recovery mode.
800607 Alternated Feeder Comp. Thickness(sensor)
800608 Alternated Feeder Comp. Pickup Diff.(recog.)
800609 Alternated Feeder Comp. Reverse(recog.)
(Contents) The feeder alternate function has worked.
(Description) Check the related feeder and take necessary measures such as
component replenishment.
