Check Code Display Section A Display Section B
801701 Teach Nozzle Nozzle Down Error.(L)
Bypass
801702 Teach Nozzle Nozzle Down Error.(H)
Bypass
801703 Teach Nozzle Recognition Teach Error.
Bypass
801704 Teach Nozzle Teach Error Data.
Bypass
801705 Teach Nozzle Lighting Check.
Bypass
801706 Teach Nozzle Nozzle Level.
Bypass
801707 Teach Nozzle Nozzle Drop
Bypass
801708 Teach Nozzle Dummy Nozzle.
Bypass
801709 Teach Nozzle Manual Bypass.
Bypass
80170a Teach Nozzle Nozzle Change Error.(Cam lock action)
Bypass
80170b Teach Nozzle Nozzle Change Error.(Cam Free action)
Bypass
80170c Teach Nozzle Cam Origin Error.
Bypass
80170d Teach Nozzle Nozzle Teach Error.
Bypass
80170e Teach Nozzle Nozzle Posture Detection
Bypass
(Contents) The nozzle to be taught was bypassed.
(Description) Follow the described instructions to reset the machine to its normal con-
dition.
When the machine cannot be set to its normal condition, consult our
service personnel for the remedy.
1.3 Machine lnformation
0511-002 2-19 AIL01ETRP
Check Code Display Section A Display Section B
801801 Teach Head Bypass Communication Error.
801802 Teach Head Bypass Head Origin.
801803 Teach Head Bypass Overtime Head Origin Return.
801804 Teach Head Bypass Unselected Nozzle Drop.
801805 Teach Head Bypass Dummy Nozzle.
801806 Teach Head Bypass Manual Bypass.
801807 Teach Head Bypass Alarm Error.
(Contents) The nozzle to be taught was bypassed.
(Description) Follow the described instructions to reset the machine to its normal con-
dition.
When the machine cannot be set to its normal condition, consult our
service personnel for the remedy.
801901 Nozzle Adjustment Nozzle UP&Down Action is not Available.
801902 Nozzle Adjustment Communication error.
801903 Nozzle Adjustment Confirm of the defective of Nozzle exchange.(Tact)
(Contents) Self-Diagnostics Error Message
(Description) Follow the described instructions to reset the machine to its normal con-
dition.
When the machine cannot be set to its normal condition, consult our
service personnel for the remedy.
801a01 Warning Operation Product started by RUN MODE "PASS" Operation.
801a02 Warning Operation The P.C.B. before component placing was conveyed from X/Y
table.
801a03 Warning Operation The P.C.B. in the middle of component placing was conveyed from
X/Y table.
(Contents) Self-Diagnostics Error Message
(Description) Confirm the displayed contents.
1.3 Machine lnformation
0511-002 2-20 AIL01ETRP
Check Code Display Section A Display Section B
801a04 Warning Operation The feeder ready button was turned on in start protection mode.
801a05 Warning Operation Cannot alternate by external start protection.
801b01 Lightning Surge Lightning Surge Protector works; Q204.
Warning
801b02 Lightning Surge Lightning Surge Protector works; Q204. Running continue.
Warning
801c01 Information This placement step was detected outside of the possible range.
This step is auto skip running.
801c02 Information Feeder carriage has been paused to avoid clash with missing com-
ponent. Please collect component before operating the feeder car-
riage.
801c03 Information Data was changed during machine worked. The changed data is
not reflected in operation until it stops or interrupts operation.
801c04 Information PCB Origin Position data is not right. Please correct a PCB Origin
Position on a "Prod Chng(Origin Pos)" screen.
801c05 Information The object of "Recognition image preservation" is not used with
current NC. Correct "Recognition image preservation" data from
the production parameter screen. Please set the function selec-
tion item in data to "Do not preserve it".
801c06 Information Source of light unit not correspond to the specified lighting method
801c07 Information Specified lighting method not correspond to nozzle of current pat-
tern
801c01 Information This placement step was detected outside of the possible range.
This step is auto skip running.
801d01 Semi-auto (continue) Production operation was interrupted for the state where PCB be-
start mode auto fore component are placed exists on XY table.
change
801e01 Placement Level Calculated data out of range. Please check library data and pat-
Data tern program data.
801f01 Warm start mode Operation was canceled for the state where the P.C.B. in the middle
auto change of component placing is on X/Y table.
(Contents) Self-Diagnostics Error Message
(Description) Confirm the displayed contents.
0511-001 2-20-1 AIL01ETRP
1.3 Machine lnformation
