Error ID Item Description
080701 Fdr.Crg. Axis Motor#1 Interlock Movement cannot take place until the index angle is adjusted.
080702 Fdr.Crg. Axis Motor#1 Interlock Pallet went out.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
080801 Fdr.Crg. Axis Motor#1 Communication error was detected.
Communication
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0511-001 2-65-2 AIL01ETRP
3.3 Error IDs and Remedial Procedures
(09 Feeder Carriage #2)
Error ID Item Description
090101 Fdr.Crg. Axis Motor #2 Origin Encoder origin was not detected.
090102 Fdr.Crg. Axis Motor #2 Origin Origin sensor (slide) was not detected.
090104 Fdr.Crg. Axis Motor #2 Origin Feedback value is indefinite.
090105 Fdr.Crg. Axis Motor #2 Origin The component pick-up (z) axis is not at origin.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
090201 Fdr.Crg. Axis Motor #2 Timing Task has not been completed unable to continue.
090301 Fdr.Crg. Axis Motor #2 Data The driver data was detected outside of the possible range.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
090401 Fdr.Crg. Axis Motor #2 Limit (+) Limit error has been detected.
090402 Fdr.Crg. Axis Motor #2 Limit (-) Limit error has been detected.
090403 Fdr.Crg. Axis Motor #2 Limit (+) (-) Limit error has been detected.
(Cause 1) Automatic or manual operation was started without all devices being zeroed after
the machine was powered and the [SYS CLEAR] button was pressed.
(Remedy 1) Press the [RETURN] button to cancel the error display.
Remove the cause of the error.
Zero all axes and re-start the operation.
0511-002 2-66 AIL01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
090502 Fdr.Crg. Axis Motor #2 User constant breakdown.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
090503 Fdr.Crg. Axis Motor #2 Main circuit encoder error
Servo Alarm
090504 Fdr.Crg. Axis Motor #2 User constant setting error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
090505 Fdr.Crg. Axis Motor #2 Combination error
Servo Alarm
090509 Fdr.Crg. Axis Motor #2 Dividing ratio setting error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
09050a Fdr.Crg. Axis Motor #2 Encorder model unmatched.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
090510 Fdr.Crg. Axis Motor #2 Overcurrent or Heat Sink Overheated.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
090530 Fdr.Crg. Axis Motor #2 Regeneration error detected
Servo Alarm
090532 Fdr.Crg. Axis Motor #2 Regenerative overload
Servo Alarm
090533 Fdr.Crg. Axis Motor #2 Main circuit power supply wiring error
Servo Alarm
090540 Fdr.Crg. Axis Motor #2 Overvoltage
Servo Alarm
090541 Fdr.Crg. Axis Motor #2 Undervoltage
Servo Alarm
090551 Fdr.Crg. Axis Motor #2 Overspeed
Servo Alarm
090555 Fdr.Crg. Axis Motor #2 Linear motors max.speed setting error
Servo Alarm
090571 Fdr.Crg. Axis Motor #2 Overload: high load
Servo Alarm
090572 Fdr.Crg. Axis Motor #2 Overload: low load
Servo Alarm
090573 Fdr.Crg. Axis Motor #2 Dynamic break overload
Servo Alarm
090574 Fdr.Crg. Axis Motor #2 Overload of Surge Current Limit Resistor
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
09057a Fdr.Crg. Axis Motor #2 Heat sink overheated
Servo Alarm
090581 Fdr.Crg. Axis Motor #2 Encoder backup error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
090582 Fdr.Crg. Axis Motor #2 Encoder checksum error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0511-002 2-67 AIL01ETRP
3.3 Error IDs and Remedial Procedures
