0511-002 2-72 AIL01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
0c0301 Head Axis Data The received version number was incorrect.
0c0302 Head Axis Data The abnormal data is received.
(Head Cam no data )
0c0303 Head Axis Data Abnormal check sum data.
0c0304 Head Axis Data Angle correct speed control data is abnormal value.
(result of calculate)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0c0401 Head Axis Communication The controller can not run.
0c0402 Head Axis Communication Controller interior is out of order.
0c0403 Head Axis Communication Cpu Communication error.(CPU2-3).
0c0404 Head Axis Communication Controller incomplete resulting in an overtime alarm.
(Cam position Return)
0c0405 Head Axis Communication Controller incomplete resulting in an overtime alarm.
(Nozzle Change)
0c0406 Head Axis Communication Controller incomplete resulting in an overtime alarm.
(Pickup position)
0c0407 Head Axis Communication Controller incomplete resulting in an overtime alarm.(CYR)
0c0408 Head Axis Communication Controller incomplete resulting in an overtime alarm.(AC)
(Cause 1) Self-Diagnostics Error Message
(Cause 2) The voltage of the stabilization power supply unit (PSU) is abnormal.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Consult our service personnel for details.
0c0501 Head Skip Not return CAM origin position.
(Cause 1) Self-Diagnostics Error Message
(Cause 2) The voltage of the stabilization power supply unit (PSU) is abnormal.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Consult our service personnel for details.
0305-001 2-73 AIL01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
0c0601 Head Alarm CAM position.
(Cam Position Return)
0c0602 Head Alarm Origin Return Action.
(Cam Position Return)
0c0603 Head Alarm Motor Out of Control
(Cam Position Return)
0c0604 Head Alarm Current Overload.
(Cam Position Return)
0c0605 Head Alarm Motor not connected.
(Cam Position Return)
0c0606 Head Alarm Solenoid not connected.
(Cam Position Return)
0c0607 Head Alarm Power line warning.
(Cam Position Return)
0c0608 Head Alarm Command not execute.
(Cam Position Return)
0c0609 Head Alarm Driver temperature warning.
(Cam Position Return)
0c0610 Head Alarm Driver temperature error.
(Cam Position Return)
0c0611 Head Alarm EEPROM error.
(Cam Position Return)
0c0612 Head Alarm Sensor error.
(Cam Position Return)
0c0613 Head Alarm Cam position self-check warning.
(Cam Position Return)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0c0701 Head Alarm(Nozzle Change) CAM position.
0c0702 Head Alarm(Nozzle Change) Origin Return Action.
0c0703 Head Alarm(Nozzle Change) Motor Out of Control
0c0704 Head Alarm(Nozzle Change) Current Overload.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
Error ID Item Description
0c0705 Head Alarm(Nozzle Change) Motor not connected.
0c0706 Head Alarm(Nozzle Change) Solenoid not connected.
0c0707 Head Alarm(Nozzle Change) Power line warning.
0c0708 Head Alarm(Nozzle Change) Power line error.
0c0709 Head Alarm(Nozzle Change) Driver temperature warning.
0c0710 Head Alarm(Nozzle Change) Driver temperature error.
0c0711 Head Alarm(Nozzle Change) EEPROM error.
0c0712 Head Alarm(Nozzle Change) Sensor error.
0c0713 Head Alarm(Nozzle Change) Cam position self-check warning.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0c0801 Head Alarm(Pickup Y-position) CAM position.
0c0802 Head Alarm(Pickup Y-position) Origin Return Action.
0c0803 Head Alarm(Pickup Y-position) Motor Out of Control
0c0804 Head Alarm(Pickup Y-position) Current Overload.
0c0805 Head Alarm(Pickup Y-position) Motor not connected.
0c0806 Head Alarm(Pickup Y-position) Solenoid not connected.
0c0807 Head Alarm(Pickup Y-position) Power line warning.
0c0808 Head Alarm(Pickup Y-position) Power line error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
