051 1-002 2-78 AIL01ETRP 3.3 Error IDs and Remedial Procedures (0d Camera X) Error ID Item Description 0d0101 Camera-X Axis Origin Output signal from the pulse motor driver was not detected. (Cause 1) This error occurs w…
Error ID Item Description
0c1106 Head Origin Return Solenoid not connected.
0c1107 Head Origin Return Power line warning.
0c1108 Head Origin Return Power line error.
0c1109 Head Origin Return Driver temperature warning.
0c1110 Head Origin Return Driver temperature error.
0c1111 Head Origin Return EEPROM error.
0c1112 Head Origin Return Sensor error.
0c1113 Head Origin Return Origin Return action time over.
0c1114 Head Origin Return Not fined Origin position.(no alarm condition)
0c1115 Head Origin Return Head communication error.
.
0c1116 Head Origin Return Cam position self-check warning.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0511-002 2-77 AIL01ETRP
0511-002 2-78 AIL01ETRP
3.3 Error IDs and Remedial Procedures
(0d Camera X)
Error ID Item Description
0d0101 Camera-X Axis Origin Output signal from the pulse motor driver was not detected.
(Cause 1) This error occurs when the optical beam of the sensor is always kept in the “E/NR”
or the “E/R” condition during zeroing operation on all axes. (E/NR: Light Emitted
and Not Received, E/R: Light Emitted and Received)
(Remedy 1) Press the [RETURN] button to cancel the error display and check if the optical
beam is always kept in the “E/NR” or the “E/R” condition due to dirt on the sensor
or because the sensor is defective.
Cover the optical beam of the sensor with a piece of paper and check if the
beam of light can be shielded or received.
0d0102 Camera-X Axis Origin Origin sensor (slit) was not detected. ; BPH7 E/R
0d0103 Camera-X Axis Origin Origin sensor (slide) was not detected. ; BPH1 E/R
0d0104 Camera-X Axis Origin Feedback value is indefinite.
0d0105 Camera-X Axis Origin The camera-x is not at origin.
0d0106 Camera-X Axis Origin The camera-x was not completely zero during the set time.
0d0201 Camera-X Axis Timing Task has not been completed unable to continue.
0d0301 Camera-X Axis Data The driver data was detected outside of the possible range.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0511-001 2-78-1 AIL01ETRP
Error ID Item Description
0d0401 Camera-X Axis Limit Limit error has been detected. ; BPH2 E/NR
0d0402 Camera-X Axis Limit Limit error has been detected. ; BPH3E/NR
(Cause 1) When Camera X was activated, the optical beam of the sensor was shielded.
(Remedy 1) Press the [RETURN] button to cancel the error display and remove the cause.
0d0601 Camera-X Axis Communication Controller incomplete resulting in an overtime alarm.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
