(11 L Conveyor Width)
Error ID Item Description
110101 L CONVEYOR WIDTH ORIGIN OUTPUT SIGNAL FROM THE PULSE MOTOR DRIVER
WAS NOT DETECTED.
110102 L CONVEYOR WIDTH ORIGIN FEEDBACK VALUE IS INDEFINITE.
110103 L CONVEYOR WIDTH ORIGIN L COVEYOR WIDTH IS NOT AT ORIGIN.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
110201 L CONVEYOR WIDTH TIMING TASK HAS NOT BEEN COMPLETED UNABLE TO
CONTINUE.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
110301 L CONVEYOR WIDTH DATA THE DRIVER DATA WAS DETECTED OUTSIDE OF
THE POSSIBLE RANGE.
(Cause 1) The "Product Change" tab sheet was opened and the manual axis operation was
performed to widen the width from the origin position. Or, the manual axis opera-
tion was performed to make the width narrower.
(Remedy 1) Cancel the error display with the [RETURN] button and perform the manual axis
operation in the correct direction.
110401 L CONVEYOR WIDTH LIMIT LIMIT (+) ERROR HAS BEEN DETECTED. ; BPH77 E/NR
110402 L CONVEYOR WIDTH LIMIT LIMIT (−) ERROR HAS BEEN DETECTED. ; BPH78 E/NR
(Cause 1) An optical beam of the sensor is shielded.
(Cause 2) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 3) The sensor is defective.
(Remedy 1) Turn off the power supply and move the conveyor width with the manual knob for
easier operation. Re-attach the light shield plate or the sensor securely (remove
the looseness).
Re-supply power to the machine and zero the L conveyor width.
Open the "Product Change" tab sheet and confirm that the L conveyor width can
be changed as specified.
If necessary, correct the "Clearance" data for the conveyor width.
(Remedy 2) Wipe off dirt on the sensor and zero the L conveyor again.
(Remedy 3) It is required to replace the sensor.
Contact our service personnel for details.
