Safe-17 AIL01E-P Safety Precautions [Front Safety Door Check] Switch When the front safety door is opened with the [OPERA TION] switch set to "RUN", the switch is activated and an error occurs. When the switch …

Safe-16 AIL01E-P

Safety Precautions

Table 1X1

Switch Name Countermeasures

[EMERGENCY STOP] Switch (1)

[EMERGENCY STOP] Switch (2)

[EMERGENCY STOP] Switch (3)

[EMERGENCY STOP] Switch (4)

Pressing one of the [EMERGENCY STOP] switches

cuts power to the following modules.

• All power sources for loads are shut off.

The power supply to the mechanisms of all motor

shafts and 24-voltage loads in the solenoid system

(SOL and SV) is shut off.

Note: The load power supply for the vacuum

pump and the DD motor is excluded. The

control power supply for the control boards

and sensors is also excluded.

0412-001

Safe-17 AIL01E-P

Safety Precautions

[Front Safety Door Check] Switch

When the front safety door is opened with the [OPERATION] switch set to "RUN", the

switch is activated and an error occurs.

When the switch is set to "SETUP", it is not activated.

Fig. 1X16 Front View

Table 1X2

Switch Name Countermeasures

When the front safety door is opened, the following mea-

sures are taken.

• All power sources for loads are shut off.

The power supply to the mechanisms of all motor

shafts and 24-voltage loads in the solenoid system

(SOL and SV) is shut off.

Note: The load power supply for the vacuum pump

and the DD motor is excluded.

The control power supply for the control

boards and sensors is also excluded.

[Front Safety Door Check] Switch

[Front Safety Door Check]

Switch

Front Safety Door

0412-001

Safe-18 AIL01E-P

Safety Precautions

[Feeder Work Area Safety Door] Switches

Fig. 1X17 Rear View

Each feeder work area safety door is provided with a [Feeder Work Area Safety Door]

switch inside as shown below.

Fig. 1X18 [Feeder Work Area Safety Door] Switches

Fig. 1X19

F2 Work Area Safety Door

[F2 Work Area Safety Door]

Switch

F1 Work Area Safety Door

[F1 Work Area Safety Door]

Switch

[FEEDER READY] Buttons
