Error ID ltem Description
440402 The Feeder Index Lever #2 The feeder index lever moves despite being held by stopper.
(Cause 1) The optical beam of the sensor was shielded.In normal cases, the sensor must be
in the "E/R" mode. (E/R: Light Emitted and Received)
(Remedy 1) Press the [RETURN] button to cancel the error display and check that the optical
beam of the sensor is in the "E/NR" mode. (E/NR: Light Emitted and Not Re-
ceived)
· Cover the optical beam of the sensor with a piece of paper to see if the optical
beam can be shielded or received and check the reaction.
· If necessary, wipe off dirt on the sensor and then perform the zeroing opera-
tion on all axes.
Note: Never detach the sensor. Otherwise, the optical axis will shift, causing
the timing to drift.
Whenever the sensor was detached, consult our service personnel for
the attachment.
440403 The Feeder Index Lever #2 The feeder index lever does not move even though stopper
was open.
(Cause 1) The optical beam of the sensor was received. In normal cases, the sensor must be
in the "E/NR" mode. (E/NR: Light Emitted and Not Received)
(Remedy 1) Press the [RETURN] button to cancel the error display and check that the optical
beam of the sensor is in the "E/NR" mode. (E/NR: Light Emitted and Not Re-
ceived)
· Cover the optical beam of the sensor with a piece of paper to see if the optical
beam can be shielded or received and check the reaction.
· If necessary, wipe off dirt on the sensor and then perform the zeroing opera-
tion on all axes.
Note: Never detach the sensor. Otherwise, the optical axis will shift, causing
the timing to drift.
Whenever the sensor was detached, consult our service personnel for
the attachment.
440501 The Feeder Adhesive Tape The structure of feeder adhesive tape lever was not activated.
(Cause 1) An error was found in the adhesive tape take-up mechanism.
(Cause 2) Self-Diagnostics Error Message.
(Remedy 1) When dirt adheres to the sensor, wipe it off.
When an error is found in the adhesive tape take-up mechanism, consult our
service personnel for the remedy.
(Remedy 2) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0305-001 2-108 AIL01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
440502 The Feeder Adhesive Tape The feeder adhesive tape lever moves despite being held by
stopper.
(Cause 1) Although the stopper was turned off while working, the lever moved down and the
optical beam of the sensor was shielded (not received).
(Remedy 1) Press the [RETURN] button to cancel the error display and remove the cause of
the error.
When the sensor is dirty and the optical beam is shielded (not received), wipe
off dirt on the sensor and then perform the zeroing operation on all axes.
440503 The Feeder Adhesive Tape The feeder adhesive tape lever does not move even though
stopper was open.
(Cause 1) Although the stopper was turned off while working, the lever did not move down and
the optical beam of the sensor was not shielded (received).
(Remedy 1) Press the [RETURN] button to cancel the error display and remove the cause of
the error.
When the sensor is dirty and the optical beam is shielded (not received), wipe
off dirt on the sensor and then perform the zeroing operation on all axes.
440601 Nozzle Change The nozzle change lever was not activated. ;BPH87 E/NR
440602 Nozzle Change The nozzle change lever moves despite being held by stop-
per.
440603 Nozzle Change The nozzle change lever does not move even though stop-
per was open.
Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
440701 Nozzle Change/Return The nozzle change/return lever was not activated. ;BPH88
E/NR
440702 Nozzle Change/Return The nozzle change/return lever moves despite being held
by stopper.
440703 Nozzle Change/Return The nozzle change/return lever does not move even though
stopper was open.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0511-002 2-109 AIL01ETRP
3.3 Error IDs and Remedial Procedures
0511-001 2-109-1 AIL01ETRP
Error ID ltem Description
440801 Cutter THE CUTTER FORWARD CONFIRMATION WAS NOT AC-
TIVATED. ; BPH32
440802 Cutter THE CUTTER RETURN CONFIRMATION WAS NOT ACTI-
VATED. ; BPH33
(Cause 1) An optical beam of the sensor was not shielded at all.
This error occurs when the cutter blades do not close completely.
Example: The cutter blades were damaged because they were activated to cut
components.
(Remedy 1) Press the [RETURN] button to cancel the error display and check the cutter
blades.
• If necessary, replace the cutter blades with new ones.
• Check the ON/OFF operation of the cutter forward movement check
photosensor (BPH32) and the cutter backward movement check photosensor
(BPH33) in the cutter section through the manual subsystem operation in the
"MNL OPN." window.
