(4a Camera Teaching/Correction)
Error ID ltem Description
4a0101 Camera X/Y Camera Through Picture Display
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4a0201 Camera Sensitivity Check Lighting Data Transmission
4a0202 Camera Sensitivity Check Camera Sensitivity
4a0203 Camera Sensitivity Check Display initialization
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4a0301 Comp Recognition Lighting Comp Recognition Lighting
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4a0401 Comp Recognition Camera Lighting Data Transmission
4a0402 Comp Recognition Camera Camera Through Picture Display
4a0403 Comp Recognition Camera Camera Offset
4a0404 Comp Recognition Camera Camera Magnification Data Transmission
4a0405 Comp Recognition Camera Dot Recognition
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0511-003 2-116 AIL01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
4a0501 P.E.C. Camera Camera Magnification Data Execution
4a0502 P.E.C. Camera Magnification Data Transmission
4a0503 P.E.C. Camera Mark Data Transmission
4a0504 P.E.C. Camera Lighting
4a0505 P.E.C. Camera Picture Taking
4a0506 P.E.C. Camera Recognition Execution
4a0507 P.E.C. Camera Camera Through Picture Display
4a0508 P.E.C. Camera Display initialization
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0511-003 2-117 AIL01ETRP
3.3 Error IDs and Remedial Procedures
(4b Others)
Error ID ltem Description
4b0101 Warning Maintenance The dust box is full of waste chip. (stop count over)
4b0102 Warning Maintenance The component box is full of waste chip. (stop count over)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Remove the cut pieces of the tape and wasted components and re-start the
automatic operation.
4b0301 ILLEGAL OPERATION THE INTERLOCK SW IS CHANGED IN RUN STATE.
(Cause 1) The [OPERATION] switch was changed over by mistake.
(Remedy 1) Change over the [OPERATION] switch to "RUN" and press the [SETUP] button.
Press the [ALL] button (entitled "ZERO") to zero all axes and re-start the produc-
tion.
4b0302 ILLEGAL OPERATION P.C.B. WAS TOOK ON CONVEYOR.
(Cause 1) An improper P.C.B. is put on the conveyor.
(Remedy 1) Press the [RETURN] button to cancel the error display and remove the improper
P.C.B.
After that, place a proper P.C.B. on the conveyor, zero all axes, and re-start the
production.
4b0303 ILLEGAL OPERATION P.C.B. REMOVE FROM CONVEYOR.
(Cause 1) A proper P.C.B. was removed from the conveyor.
(Remedy 1) Press the [RETURN] button to cancel the error display and place a proper P.C.B.
on the conveyor, Then, zero all axes and re-start the production.
4b0304 ILLEGAL OPERATION THE OPERATION SW IS CHANGED IN EXCEPT STOP
STATE.
(Cause 1) The [OPERATION] switch was changed over.
(Remedy 1) Change over the [OPERATION] switch to the correct mode and press the [RE-
TURN] button. Then, continue the operation.
4b0305 ILLEGAL OPERATION THE OPERATION/SETUP SW HAS BEEN ENABLED
WHILE THE BACKPANEL IS USE.
(Cause 1) The [OPERATION] switch was changed over.
(Remedy 1) Change over the [OPERATION] switch to the correct mode and press the [RE-
TURN] button. Then, continue the operation.
3.3 Error IDs and Remedial Procedures
0511-003 2-118 AIL01ETRP
