Error ID ltem Description
4b030c ILLEGAL OPERATION P.C.B. REMOVE FROM INPUT CONVEYOR.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4b030d ILLEGAL OPERATION P.C.B. REMOVE FROM OUTPUT CONVEYOR.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4b0401 Machine Interface Signal Check the P.C.B. input machine on conveyor.
Input machine P.C.B. existence signal turn to available for
setup.
4b0402 Machine Interface Signal Check the P.C.B. output machine on conveyor.
Output machine P.C.B. existence signal turn to available for
setup.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4b0501 XY table chute X/Y Chute Lower Limit not exist.
4b0502 XY table chute X/Y Chute Upper Limit not exist.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(4c Unit P.C.B. B.B.R. Mode)
Error ID ltem Description
4c0101 B.B.R. All unit P.C.B.’s ware detected as defective.
(P.C.B. on XY-Table)
4c0102 B.B.R. All unit P.C.B.’s ware detected as defective.
(P.C.B. on Transfer Conveyor)
4c0201 Unit P.C.B. B.B.R. Information Not exist available information.
(P.C.B. on Transfer Conveyor)
4c0202 Unit P.C.B. B.B.R. Information Not exist available information.
(P.C.B. on Transfer XY-Table)
4c0203 Unit P.C.B. B.B.R. Information Communication data is illegal information.
4c0301 Unit P.C.B. B.B.R. Product P.C.B count is complete.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Follow the described instructions and reset the machine to its normal condition
.
0511-003 2-120 AIL01ETRP
3.3 Error IDs and Remedial Procedures
(4f Program Error)
Error ID ltem Description
4f0101 PROGRAM ERROR Error in Sequence Controller! Operation Not Secured
4f0201 PROGRAM ERROR Error in Polling Task (CPU2)! Operation Not Secured
4f0202 PROGRAM ERROR Error in Polling Task (CPU3)! Operation Not Secured
4f0203 PROGRAM ERROR Error in Pick-Up Sequence!
Error Sequence is started Recovery mode.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0511-003 2-121 AIL01ETRP
