Error ID ltem Description
600206 Nozzle Bypass Nozzle Level
(Cause 1) The nozzle being used has dropped.
(Remedy 1) Check the pertinent nozzle.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
600207 Nozzle Bypass Nozzle Drop
(Cause 1) The nozzle being used has dropped.
(Remedy 1) Check the pertinent nozzle.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
600208 Nozzle Bypass Dummy Nozzle
600209 Nozzle Bypass Manual Bypass
(Cause 1) This appears when some nozzles are bypassed manually.
(Remedy 1) When the [Reset Noz. Bypass] button is pressed in the "Head/Noz. Bypass" tab
sheet of the "OPN. MODE" window (submenu), the manual bypass designation
of all nozzles is all canceled.
60020a Nozzle Bypass Nozzle Change Error. (Cam lock action)
60020b Nozzle Bypass Nozzle Change Error. (Cam Free action)
60020c Nozzle Bypass Cam Origin Error.
60020d Nozzle Bypass Nozzle Teach Error.
60020e Nozzle Bypass Nozzle Posture Detection
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0511-003 2-126 AIL01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
600301 Head Bypass Communication Error
600302 Head Bypass Head Origin
600303 Head Bypass Overtime Head Origin Return
600304 Head Bypass Unselected Nozzle Drop
600305 Head Bypass Dummy Nozzle
600306 Head Bypass Manual Bypass
600307 Head Bypass Alarm Error
(Cause 1) Self-Diagnostics Error Message
(Cause 2) The voltage of the stabilization power supply unit (PSU) is abnormal.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Consult our service personnel for details.
600401 Nozzle Level Nozzle Level (Low) Was More Than Tolerance.
600402 Nozzle Level Nozzle Level (Low) Was Less Than Tolerance.
600403 Nozzle Level Nozzle Level (High) Was More Than Tolerance.
600404 Nozzle Level Nozzle Level (High) Was Less Than Tolerance.
(Cause 1) This error occurs when there is a big difference in nozzle levels in comparison with
the master nozzle during teaching operation.
(Remedy 1) Re-teach the data of the master nozzle.
600501 Master Head Offset Linear Measure System Was At High Position.
600502 Master Head Offset Linear Measure System Was At Low Position.
(Cause 1) The master nozzle or the linear measure detection sensor may not be attached
correctly.
(Remedy 1) Attach the master nozzle correctly.
It is required to adjust the linear measure detection sensor after it is attached
correctly.
0403-002 2-127 AIL01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
600601 Head Origin Offset Total Designate Loop Exceeded Time.
(Cause 1) Each head deviated from its origin position in comparison with the master head.
(Remedy 1) Check if the master head is not loose.
600701 Comp. Thickness Teach Component Thickness Was Less Than Tolerance.
600702 Comp. Thickness Teach Component Thickness Was More Than Tolerance.
(Cause 1) A mistake is found in the component thickness data of the component library data.
(Remedy 1) Set the component thickness data correctly.
600801 Recog. Data Teach Recognition Error Code.
600901
Trash Teach Error Code. Recognition Error Code.
Note: Refer to "4. Troubleshooting on Recognition System" for details.
0305-001 2-128 AIL01ETRP
3.3 Error IDs and Remedial Procedures
