Safe-40 AIL01E-P
Safety Precautions
Table 1X17
No. Alert Labels and Description
*28
Description
z Never perform the automatic operation with the feeder carriage cover(s) and the
feeder work area safety door(s) being kept open.
z Never modify the [EMERGENCY STOP] switches, the safety doors, etc.
z Do not put your hand or head in the moving ranges of the machine during
operation.
z Only trained personnel should be allowed to operate the machine.
z Operate the machine with the covers being attached.
z In principle, only one person should operate the machine.
0502-002
Safe-41 AIL01E-P
Safety Precautions
5. Precautionary Items for Correct Operations
Requirements for Installation
Be sure to fulfill the following requirements for safety purposes.
• Overvoltage Category : Category III
• Pollution Degree : 3
z Overvoltage Categories refer to the level of Impulse Withstand Voltage protection
provided at the specified Pollution Degree.
Category III : Primary circuits of a device to which power is directly
supplied from the power distribution panel, and circuits from
the distribution panel to outlets.
The term was changed from "Installation Category" to "Overvoltage
Category".
z "Pollution Degree" is a degree of pollution severity.
Pollution Degree 3: Conductive pollution or dry nonconductive pollution
that becomes conductive due to condensation occurs.
To be found in industrial environment or construction
sites (harsh environments).
Note
0502-002
Safe-42 AIL01E-P
Safety Precautions
Precautionary Measures before Installation
If the machine is installed in unsatisfactory environmental conditions, it may malfunction
due to damage or breakdown.
To avoid this, make preparations to install the machine as follows.
When the machine is scheduled to be transferred to another place, please contact the
marketing department or sales agency of Hitachi High-Technologies beforehand.
z Select a place solid enough to support the mass of the machine.
It is recommended that the machine should be installed on the first floor.
When the machine has to be installed on a floor other than the first one,
please contact the marketing department or sales agency of Hitachi
High-Technologies for details.
z Avoid any place that vibrates severely.
z The ambient temperatures must be 20±10°C and humidity 30 to 80%. Any dew
condensation must be avoided.
When the machine is transferred to another place and the ambient temperature rises more
than the surface of the machine, dew may condense under the condition described below.
Note that dew condensation may cause the machine to break down.
Condition of Dew Condensation
Dew may condense when the difference (based on "Humidity (%)") between the ambient
temperature of the destination (the place where the machine was transferred) and the
surface temperature of the machine reaches the values or more in the table below.
Humidity (%) of Destination
Differences between Ambient Temperature
of Destination and Surface Temperature of Machine
80 3 °C or more
70 6 °C or more
60 8 °C or more
50 10 °C or more
40 14 °C or more
30 18 °C or more
Note
