4-18 0606-001 A(M829WBL--0004) 8$,2 ᵔ,/%,1/ 8$, ᵔ,/%,1/ Head U/D Interlock (MB) Motion Control Board -U82 From MB-B3103 OUT Power Supply Power Supply Power Supply Motion Control Board -U84 -X8203: T …
4-170606-001 D(M829WBL--0003)
8$,2 ᵔ,/%,1/
8$, ᵔ,/%,1/
-U12 (UB32) Main Body
(From K3 34)
(From -K4 34)
(From K3 33)
(From -K4 33)
Emergency Stop
Safety Monitor
Safety Monitor for
Left Cover
Disengaged Suppressor
Detection (A)
Disengaged Suppressor
Detection (B)
Multi-Layer Tray (L)
Multi-Layer Tray (L)
Feeder Disengaged
Latch Detection (A)
Feeder Disengaged
Latch Detection (B)
From A-B3101 OUT
From B-B3101 OUT
CB Error (A-Y2) CB Error (A-Y1) CB Error (A-X) CB Error (Beam A Integral)
CB Error (B-Y2) CB Error (B-Y1) CB Error (B-X) CB Error (Beam B Integral)
From MA-B3103 OUT
Nozzle U/D Interlock (MA)
Nozzle U/D Interlock (MB)
Beam A Main Power OFF
Detection
Beam B Main Power OFF
Detection
Beam A CB Error Monitor
Beam B CB Error Monitor
Head U/D Interlock (MA)
Blue
Black
Brown
Orange
Note 2
Note 2
Blue
Black
Brown
Orange
Safety Cover Monitor in
Conveyor Seotion
Component Pickup
Error Detection (A)
Component Pickup
Error Detection (B)
4-180606-001 A(M829WBL--0004)
8$,2 ᵔ,/%,1/
8$, ᵔ,/%,1/
Head U/D Interlock
(MB)
Motion Control Board -U82
From MB-B3103
OUT
Power Supply
Power Supply
Power Supply
Motion Control Board -U84
-X8203: To 22
-X8203: To 47
-X8303: To 22
-X8303: To 47
Motion Control Board -U83
-X8303: To 47
-X8303: To 22
SS C-NET Route Change
Multi-Layer Tray SW (Rear)
Multi-Layer Tray SW (Front)
4-190606-001 -(M829WBL--0005)
8$, ᵔ,/%287/
8$, ᵔ,/%287/
Beam A
Main Power Control
Beam B
Main Power Control
MA Module
Main Power Control
MB Module
Main Power Control
Conveyor L
Main Power Control 1
Conveyor L
Main Power Control 2
Vacuum Pump 1
Power Control
-X0702:
To 2
-X0702: To 1
Power ON for
Input/Output Machines
I/F (L)-U07 for
Input/Output Machines
-U27 (UB21/Relay Board 2)
-U26 (UB20/Relay Board 1)
-U27 (UB21/Relay Board 2)
Motion Control Board -U82
-X8203: To 1
-X8203: To 23
Motion Control Board -U82
-X8203: To 2
-X8203: To 48
Beam A
Emergency Stop Command
Beam B
Emergency Stop Command
MA Module
Emergency Stop Command
MB Module
Emergency Stop Command
Conveyor L
Emergency Stop Command
Conveyor Width L Interlock
Motion Control Board -U83
-X8303: To 1
-X8303: To 23
Motion Control Board -U83
-X8303: To 26
-X8303: To 48
Motion Control Board -U84
-X8403: To 26
-X8403: To 48
Motion Control Board -U84
-X8403: To 1
-X8403: To 23
