KLG-1608 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level 1 KLG-M1309-00 …
KLG-1608
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KLG-M1309-00 COVER 9 ASSY. 1 /
Í
2 KLG-M1309-A1 COVER 9 1 /
Í
3 KLG-M1347-00 PLATE,MAGNET 2 /
Í
4 KLG-M1348-00 BRACKET,KEY 1 /
Í
5 KLY-M17L3-00 HANDLE 1 /
6 KLG-M134B-00 BRKT.,BAR 2 /
Í
7 KLG-M134C-00 STOPPER,DOOR 1 /
Í
8 KLG-M134D-01 SHAFT,STOPPER 1 /
Í
9 KLG-M134S-00 WASHER 013 38 /
Í
10 KLG-M134T-00 WASHER 08 38 /
Í
11 KLG-M134V-01 CAP,STOPPER 1 /
Í
12 KLG-M1365-01 TAPE,RAIL 8 /
Í
13 KLG-M1365-01 BRKT.,STOPPER 1 /
14 KGS-M1360-00 BOLT 2 /
Í
15 KGS-M1360-10 BOLT 4 /
Í
16 KHY-M9153-00 DAMPER B 2 /
17 KKX-M13D7-00 SEAL 2(YAMAHA) 1 /
Í
18 KL0-M1374-00 PLATE 1, SCHMEASAL 1 /
Í
19 KW7-M5127-00 SAFETY SWITCH KEY 1 /
Í
20 91312-03004 BOLT,HEX.SOCKET HEAD 4
21 91312-04006 BOLT,HEX.SOCKET HEAD 2
22 91312-04010 BOLT,HEX.SOCKET HEAD 1
23 91312-05008 BOLT,HEX.SOCKET HEAD 12
24 91312-05016 BOLT,HEX.SOCKET HEAD 4
25 92902-04200 WASHER, PLAIN 3
26 92902-05200 WASHER, PLAIN 2
27 92902-05600 WASHER, PLAIN 2
28 95302-03600 NUT, HEXAGON 8
29 91312-04008 BOLT,HEX.SOCKET HEAD 3
30
31
32
33
34
35
36
37
38
No. Part No. Part Name Q’ty Remarks Rev. Rank Level
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
2
4
Acrylic door
Cover
