YSB55w_KLG_MPL - 第25页
KLG-1608 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level 1 KLG-M653M-A0 …
KLG-1608
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KLG-M653M-A0 SENS,HEADA FLOW ASSY 1 /
Í
2 KLG-M653M-B0 SENS,HEADB FLOW ASSY 1 B Head /
Í
3 KLG-M711A-00 PLATE 1, SIDE 1 /
Í
4 KLG-M711B-00 PLATE 2, SIDE 1 /
Í
5 KLG-M711C-00 PLATE, BASE 1 /
Í
6 KLG-M711D-00 PLATE, VALVE 1 /
Í
7 KLG-M711E-00 PLATE 1, HNS 1 /
Í
8 KLG-M711F-00 PLATE 2, HNS 1 /
Í
9 KLG-M711G-00 COVER 1 1 /
Í
10 KLG-M711H-00 COVER 2 1 /
Í
11 KLG-M711N-00 PANEL, R 1 /
Í
12 KLG-M711P-00 PLATE 1, SIDE 1 B Head /
Í
13 KLG-M711R-00 PLATE 2, SIDE 1 B Head /
Í
14 KLG-M711S-00 COVER 1 1 B Head /
Í
15 KLG-M711T-00 COVER 2 1 B Head /
Í
16 KLG-M711V-00 PANEL, R 1 B Head /
Í
17 KLG-M712B-00 COVER 3 1 /
Í
18 KLG-M712C-00 COVER A 1 /
19 KLG-M712D-00 BRKT., COVER A 1 /
Í
20 KLG-M712E-00 BRKT., COVER B 1 B Head /
Í
21 KLG-M712J-00 COVER 3 1 B Head /
Í
22 KLG-M712N-00 COVER B 1 B Head /
23 KLG-M712V-00 COVER, R 1 /
Í
24 KLG-M712W-00 COVER, R 1 B Head /
Í
25 KLY-M17L3-000 HANDLE 1 /
Í
26 KLG-M7600-00 FID. CAM. ASSY. 1 /
Í
27 90990-01J038 BOLT HEX,SOCKET HEAD 6
28 91312-03004 BOLT HEX,SOCKET HEAD 4
29 91312-03005 BOLT HEX,SOCKET HEAD 52
30 91312-03006 BOLT HEX,SOCKET HEAD 2
31 91312-03008 BOLT HEX,SOCKET HEAD 4
32 91312-03025 BOLT HEX,SOCKET HEAD 4
33 91312-03030 BOLT HEX,SOCKET HEAD 4
34 91312-04008 BOLT HEX,SOCKET HEAD 10
35 91312-05014 BOLT HEX,SOCKET HEAD 2
36 98502-03005 SCREW PAN HEAD 3
37
38
No. Part No. Part Name Q’ty Remarks Rev. Rank Level
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
4
1
Body Head Assy
Head
