Contents KLB-1608 7 Fluxer Section Flux Plate .................................................. 7-1 Pneumatic / Detection ............................... 7-2 8 Pump Section V acuum Pump .................................…
Note
Rank A : The functions of these parts gradually deteriorate with operating time.
Rank B : The machine stops immediately if the functions of these parts are disabled.
Rank C : The machine still operates even if the functions of these parts are disabled,
because there are many parts.
Rank E : The functions of consumable part gradually deteriorate with operating time.
/ : Maintenance is excluded (The screws are also equal, display is omitted)
Level
: Aims to undergo basic maintenance training and have the capability to do the
job.
Level
r
: Yamaha Corp. aims to render exclusive training
Level
Í
: Yamaha Corp. Service Engineering
Rev.
: It had a change without the compatibility. Please be careful at the time of the
parts ordering.
Level column
Make use of these as reference, “
•
r
•×”, as mentioned in the Level column.
“
” It is based on taking the basic maintenance training, and being able to do
equal work.
“
” Please contact our company service when it is judged that the customer’s
condition difcult.
From the problem that arises from these, we cannot assume responsibility such as
accidents.
NOTE
RankA: 機能が徐々に失われる可能性のある部品。
RankB: 機能を失うとマシンの即停止に繋がる部品。
RankC: 機能を失っても複数あるのでマシンの即停止とはならない部品。
RankE: 機能が徐々に失われていく消耗部品。
／ :メンテナンス対象外（ネジ類も同等、但し表示省略）
Level
: 基礎メンテナンストレーニングを受けた方、又は同等の作業ができる方が対象。
Level
r
: ヤマハの専用トレーニングを受けた方が対象です。
Level
Í
: ヤマハのサービスマンが対象です。
Rev.
: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
Level 欄について
Level 欄に記載されている
“
•
r
•×”
はご 参 考としてご 活 用ください。
“
”
は基礎メンテナンストレーニングを受けた方、又は同等の作業ができる方を
基 準 にして おりま す。
“
”
であってもお客様が難しいとご判断された時は弊社サービスまでご連絡ください。
これらに起因する不具合、事故等についての責任は負いかねます。
Contents
KLB-1608
7 Fluxer Section
Flux Plate ..................................................7-1
Pneumatic / Detection ...............................7-2
8 Pump Section
Vacuum Pump ...........................................8-1
9 Dump Section
Dump Box .................................................9-1
10 Controller Section
Controller ................................................10-1
11 Exterior, etc. Section
Exterior, etc. ............................................ 11-1
12 Wafer Elevation Section
EL / Foot .................................................12-1
Rack Assy ...............................................12-2
Cover Assy ..............................................12-3
Door Assy ................................................12-4
13 Wafer Con. Section
Shuttle .....................................................13-1
Tramsport ................................................ 13-2
Base / Mainte ..........................................13-3
Clamp Assy ............................................. 13-4
1 Base Section
Sub Assy ................................................... 1-1
2 Cover Section
Right Cover / Muzzle .................................2-1
Left Cover / Muzzle ...................................2-2
Center Cover .............................................2-3
Acrylic door ...............................................2-4
Rear Cover ................................................2-5
Base F. Cover / Ups ..................................2-6
Base R. Cover ...........................................2-7
3 Moving-axis Section
Y Axis Cable Stay / Air ..............................3-1
4 Head Section
Body Head Assy........................................ 4-1
Z Axis ........................................................4-2
5 Nozzle Section
Nozzle .......................................................5-1
6 Conveyor Section
Belt / Sensor .............................................6-1
Body / Sensor AMP ................................... 6-2
CV Motor Assy L. ......................................6-3
CV Motor Assy R. .....................................6-4
CV Motor Assy 2 / 3 / 4 .............................6-5
KLB-1608
14 Wafer Ejector Section
Ejector Head ...........................................14-1
15 Flip Head Section
Head Assy ...............................................15-1
Shank / Dust Box ....................................15-2
16 Wafer Traverser Section
Valve Panel Assy .................................... 16-1
17 Wafer Shuttle ST Section
Valve Panel ............................................. 17-1
Shank ......................................................17-2
18 Tools Section
Tools ........................................................18-1
