3 Ordering information and package supplied V ision Teach Station 5.x.x User Manual 3.2 Cameras and assembly kits 05/2019 Edition 24
Vision Teach Station 5.x.x User Manual 3 Ordering information and package supplied
05/2019 Edition 3.2 Cameras and assembly kits
23
NOTE 3
Figure 3.2 - 8
shows the position at which the component camera (item 1) is mounted on the
vision teach station. The camera is turned 180° about the horizontal on the placement machine.
Only components that are no larger than the field of vision of the component camera (single
measurement) can be taught at the vision teach station. Multiple measurements must be taken
on the machine. Detection of the orientation of asymmetrical package forms is not supported on
the vision teach station.
3 Ordering information and package supplied Vision Teach Station 5.x.x User Manual
3.2 Cameras and assembly kits 05/2019 Edition
24
Vision Teach Station 5.x.x User Manual 4 Setting up the vision teach station
05/2019 Edition 4.1 Requirements for the installation site
25
4 Setting up the vision teach station
4.1 Requirements for the installation site
4.1.1 Ambient conditions
The vision teach station is approved for use in production and in the office. The area around it must
be clean and free from dust.
4.1.2 Electrical connection
4
Tab. 4.1 - 1 Electrical ratings
4
4.1.3 Set-up location for the base module
CAUTION 4
The base module weighs around 30 kg.
You should therefore place the base module on a stable surface that is clean and level.
Two people will be needed to move the base module because of the weight.
Component Supply voltage
Base module 100 VAC to 240 VAC, 50/60 Hz
PC with wide-range power supply
PC with 115 VAC/230 VAC changeover switch
100 VAC to 240 VAC, 50/60 Hz
100 VAC to 127 VAC, 200 VAC to 240 VAC
TFT monitor with wide-range power supply 100 VAC to 240 VAC, 50/60 Hz
