Vision Teach Station 5.x.x User Manual 7 Software
05/2019 Edition 7.1 Supported SIPLACE Pro versions
53
7 Software
7
NOTE
When we supply a vision teach station, the software is already fully installed on the computer.
The computer can be started up and used immediately. All software packages needed for the
installation are supplied as standard.
As of Release 19-2 (R19-2) Windows 7 is no longer supported.
7.1 Supported SIPLACE Pro versions
At present, the vision teach station supports the following SIPLACE Pro versions:
7
Tab. 7.1 - 1 Currently supported SIPLACE Pro versions
*) Valid software version of the respective release
**)
Valid package of the respective release
Software
Vision Teach Station
SIPLACE Pro Upgrade kit required
V5.x.x*)
from V5.0 SP1
Installation Package Vision Teach Station Collection,
item no. 00117257-xx **)
7
NOTE
The Vision Teach Station only supports certain Windows 10 x64 versions from R19-2 onwards.
The system requirements (supported operating system and database variants) and an
overview of the interoperable products can be found in the Software Version Description
ASM Support Media, item no. [00900052-xx], of the respective release.
7 Software Vision Teach Station 5.x.x User Manual
7.2 Software upgrade 05/2019 Edition
54
7.2 Software upgrade
NOTE
It is possible to run the VTS on the SIPLACE LAN, and thus access other SIPLACE Pro databases
(version 5.0 SP1). If you want to use this feature, you will have to reinstall the computer to
ensure that the host name and IP address are unique (see section 7.3
, page 59). 7
Please also read sections 9.3 and 9.4 from page 68.
CAUTION: 7
Following items are important for the older software packages 00376902, 00385200 and
00387300:
When you install the software, make sure that the version of SIPLACE Pro matches the vision
teach station software (as shown in table 7.1 - 1
on page 53). The install routine does not check
the versions.
You should therefore check which versions of the software packages are installed before star-
ting the installation.
Carry out the installation in the order described below.
NOTE 7
As of Vision Teach Station version 4.1.1 you can update the Vision Teach Software independently
of the SIPLACE Pro version, if at least SIPLACE Pro V5.05SP1 is installed.
Please note that some of the new features (see section 7.4
on page 60) are only available with
SIPLACE Pro V7.0 or higher.
For this, simply deinstall the Vision Teach Station software as described in the last item in
section 7.2.3
on page 55.
Then install the new Vision Teach Station version as described in section 7.2.4.4 on page 58.
NOTE 7
To install or remove the software you will need access with administrator rights
You will find the latest information on the setup CD and in the "ReadMe.txt" file.
