Vision Teach Station 5.x.x User Manual 1 Overview 05/2019 Edition 7 1 Overview This document de scribes the Vision Teach Station Version 5.x.x. Th e vision teach station is a system for creating and testin g package form…
6
Contents User Manual Vision Teach Station 5.x.x User Manual
05/2019 Edition
10 Exchange of data between the vision teach station and
the production line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10.1 Package form descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10.1.1 Exchanging data by XML export/import. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10.1.2 Access via the SIPLACE LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10.2 Measurement contexts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
10.2.1 Saving measurement contexts in 60x station version . . . . . . . . . . . . . . . . . . . . . . 74
10.2.2 Saving measurement contexts in 70x station version . . . . . . . . . . . . . . . . . . . . . . 74
10.2.3 Loading measurement contexts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
10.2.4 Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
10.2.5 Display of station measurement contexts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
10.2.5.1 Local storage of the station measurement contexts . . . . . . . . . . . . . . . . . . . . . . . 77
11 Measuring components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
11.1 Preparing components for the measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
11.1.1 Placing the component on the component support . . . . . . . . . . . . . . . . . . . . . . . . 79
11.2 Measuring the component . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
11.2.1 General order for programming the PF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
11.2.2 Programming steps with the vision teach station . . . . . . . . . . . . . . . . . . . . . . . . . 84
12 Coordinate systems of the component cameras . . . . . . . . . . . . . . . . . . . . . . 87
13 Focus distances of the component cameras . . . . . . . . . . . . . . . . . . . . . . . . . 89
Vision Teach Station 5.x.x User Manual 1 Overview
05/2019 Edition
7
1 Overview
This document describes the Vision Teach Station Version 5.x.x. The vision teach station is a
system for creating and testing package form descriptions for components to be processed on SI-
PLACE
®
placement machines.
1
Fig. 1.0 - 1 Vision teach station with type 33 component camera
1 Overview Vision Teach Station 5.x.x User Manual
1.1 Description 05/2019 Edition
8
The vision teach station essentially consists of the following components:
– Base module with electronic circuits and component camera (see Fig. 1.0 - 1
, page 7)
– PC (Recommendation as of 2019: SIMATIC IPC 647C)
Preinstalled operating system Windows 7 (64-bit) or Windows 10 (64-bit) 1
SIPLACE vision image processing software 1
SIPLACE Pro database server 1
2 x PCI for camera interfaces: CAN bus card and camera bus card 1
The hotlink driver and CAN bus card driver will be installed with the Vision Teach Station soft-
ware. 1
The possible configurations are described in chapter 3
.
1.1 Description
The vision teach station is used to create and test descriptions for package forms for any place-
ment machine and to run component inspections.
The package form descriptions thus created may be stored in the SIPLACE Pro database on the
vision teach station and transferred to the SIPLACE Pro database of the production system. You
also have the option of loading vision measurement contexts from placement machines to the vi-
sion teach station, where they can be analyzed. Only multiple component measurements are not
yet possible on the placement machine.
1.2 Advantages
The major advantage of this offline system is that it is totally independent of the production system,
and no production system resources have to be used for creating and testing package form
descriptions. As a result, there is no loss of productivity due to the description and testing of
package forms. The time taken to introduce new products can also be considerably reduced with
this independent system.
