Softwar e Module No Constant Name Classification Va l u e Unit Description 22 OPT_T APE_LINK Use 0 Const Whether the Auto Link of the part supplied from a tape feeer is used or not.. 0: AUTO LINK 1: NOT LINK 23 OPT_STICK…
Software
Module
No
Constant Name Classification
Value
Unit Description
9
OPT_SIG_PART_EMPTY Use 13 Const
Combinations of the following setups are used.
1: Part Empty Warning (Yellow/Blue)
2: Part Empty Error (Red)
4: PCB Wait Warring (Yellow/Blue)
8: Bypass (Safe Guard) Warring (Yellow/Blue)
15
OPT_BUZONOFF Use 2 Const
0 : When an error occurs, the buzzer turns on always.
1 : When an error occurs, the buzzer turns off always.
2 : When an error occurs, the buzzer turns on selectively.
61
System
OPT_PCB_WAIT_WARNING_TIME
Use 20 sec
When waiting for the PCB in the Run state, the tower lamp signal is
changed after a given period of time (according to the setup of the
system Const #9).
10
OPT_IQ_FEEDER Use 0 Const
0 : The IT Feeder is not used.
1 : Use the front IT Feeder.
16 : Use the rear IT Feeder.
17 : Use the front and rear IT Feeder.
Feeder
20
System
OPT_FEED_OVER Use 34 Const
The Use fort the setting of the feeder unlock sensor.
>> D0-D3 : Front D4-D7 : Rear
0 : No Check(NO) 1 : Check(CH) 2 : INT Check(INT)
Value: Front, Rear
0 : NO, NO
1 : CH, NO
2 : CH-INT, NO
16 : NO, CH
17 : CH, CH
18 : CH-INT, CH
32 : NO, CH-INT
33 : CH, CH-INT
34 : CH-INT, CH-INT
Software
Module
No
Constant Name Classification
Value
Unit Description
22
OPT_TAPE_LINK Use 0 Const
Whether the Auto Link of the part supplied from a tape feeer is used or
not..
0: AUTO LINK
1: NOT LINK
23
OPT_STICK_LINK Use 0 Const
Whether the Auto Link of the part supplied from a stick feeder is used or
not..
0: AUTO LINK
1: NOT LINK
28
OPT_NO_FEEDER_CHG Use 0 Const
0: Feeder Change Button Use
1: Feeder Change No Use
59
OPT_TAPE_CLAMP Use 8 Const
0: Not Used.
1: Check for the tape feeder clamping when feeding the part.
2: Perform periodical check continuously.
4: Perform check when downloading the PCB.
8: Skip the feeder that is not clamped.
62
OPT_TAPE_INDEX Use 1 Const
0 : Do not perform check.
1 : Perform check at the time of feeding and generate the Emergency
error when
timeout occurs.
65
OPT_TAPE_LINK_OTHERSIDE Use 0 Const 0: Not Used , 1: Use
70
System
OPT_DUMPRATIO_IMPROVE Use 0 Const
0: Not use the feeder adjust function.
1: Use the feeder adjust function.
11
OPT_BADFIRST Use 0 Const
0 : Mark the fiducial mark first.
1: Mark the bad mark first.
Fiducial
69
System
OPT_MAN_MENU_DISABLE Use 0 Const
0:Normal
3: Disable the windows for the manual fiducial input function and retr
y
function.
Software
Module
No
Constant Name Classification
Value
Unit Description
72
OPT_FID_DIST_CHK Use 0 Const
0: The function to check the distance between fiducials is not used.
1: Check the distance between fiducials and if it exceeds the allowable
value (1mm), an error occurs.
12
OPT_TRAYTIME Use 1 Const
0 : Change the pallet in basic mode, which is stable.
1 : Change the pallet quickly.
2 : Change the pallet quickly at the maximum speed.
16
OPT_TRAY_NONSTOP Use 0 Const
For determining whether to set the non-stop function of the FW12M/S
tray feeder. It must be set to 0 when using the non-stop function of
another model.
0 : Not Using the Tray Non Stop.
1 : Using
24
OPT_TRAY_LINK Use 0 Const
Whether the Auto Link of the tray part is used or not.
0: AUTO LINK
1: NOT LINK
Tray
68
System
OPT_NONSTOP_METHOD Use 0 Const
Master/Slave: 0
Master/Master: 1
1Slot Buffer: 2
13
OPT_AUTOSKIP Reserved 0 Const
When there is no part or an error occurred during operation, the function
is used to perform the skipped work after skipping the corresponding
placement on the PCB and finishing the work on the PCB.
0 : The auto skip function is not used.
1 : Use the auto skip function.
Option
25
System
OPT_HOME_METHOD Use 15 Const
1: Once the XY homin
g
is performed before actual placement, it is not
performed newly.
2: Once the Z homin
g
is performed before actual placement, it is not
performed newly.
4: Once the R homing is performed before actual placement, it is not
performed newly.
8: Once the MIR homin
g
is performed before actual placement, it is not
performed newly.
16: Once the BUT homin
g
is performed before actual placement, it is not
performed newly.
