Software
Module
No
Constant Name Classification
Value
Unit Description
21
CONV_JOG_DIR Use 0 Const
0: Right Key + Dir,
1: Left Key + Dir
22
CONV_WIDTH_JOG_DIR Use 0 Const
0: Down Key + Dir
1: Up Key - Dir
23
CONV_FIX_TYPE Use 0 Const
0 : Standard of front side
1 : Standard of rear side
24
BOARD_FLOW_METHOD Use 0 Const
0 : Normal
1 : Back Return
27
CONV_1_TYPE Use 1 Const
Type of the conveyor
0: 1 stage Conveyor
1: 3 stage Conveyor
2: 3 stage motor conveyor
28
(CONV_2_TYPE) Reserved 0 - Not use.
29
CONV_1_AUTOWIDTH Use 1 Const
Whether the automatic width adjustment function is available or not.
0: Unavailable
1: Available.
30
(CONV_2_AUTOWIDTH) Reserved 0 - Not used.
31
BOARD_FLOW Use 0 Const
PCB transfer direction (PCB Flow)
0 : Left to right
1 : Right to Left
32
TMV_PCB_DELAY Use 300 msec
The time during which the PCB has been continuously pushed since
stopping by reducing the speed after the detection by the work sensor.
Push the PCB further to make it contact the placement stopper.
33
TMV_STP Use 3000 msec Timeout when operating the stopper related to the conveyor.
34
Factory
TMV_BUT Use 3000 msec Timeout when operating the BUT.
Software
Module
No
Constant Name Classification
Value
Unit Description
35
TMV_PIN_DELAY Use 200 msec
The dela
y
time until the hole fix sensor do
g
is detected since the BUT
moved up.
36
TMV_EDGE Use 3000 msec Timeout in operating the edge fix.
37
TMV_IN Use 10000
msec Timeout in transferring the PCB from a zone to next zone.
38
TMV_OUT Use 10000
msec Timeout in transferring the PCB to the next machine.
39
TMV_OUT_PUSH Use 2000 msec
The time durin
g
which the PCB is pushed continuousl
y
when it is out of
the detection range of the ‘Out Sensor’ while transfering the PCB.
85
TMV_EDGE_DELAY Use 300 msec
0: The sensor for the Edge Fix is used.
Others: It is recognized that the edge fix functioned properly after the
given delay without the sense of the edge fix sensor. (300msec)
27
LARGE_PCB_SIZE_X 0
Default : 0 ,
Input the corresponding value when setting the X size of the large PCB
to more than 460mm.
95
BUT_DOWN_DELAY Use 500 msec
Delay until operating the work zone conveyor after the BUT UP sensor
has been turned off.
96
Debug
CONV_OUT_DEC_TIME Use 200 msec
Time delay from the time the conveyor was stopped after the PCB had
been detected by the Out Zone Sensor until it starts to move.
Docking 63
System OPT_DC_SAFETY Use 4 Const
Safety related sensor for the docking cart can be checked for each
option.
0: Check all safety sensors
1: Do not check the left/right docking detection sensor.
2: Do not check the door open state.
4: Do not check the docking cart cable connection state.
Mir 32
System OPT_USE_MIR_SAFETY Use 0 Const
Currently, it is set so that it does not change according to the value.
0: Not used
1: Used only when performing the homing
2:
Software
Module
No
Constant Name Classification
Value
Unit Description
34
OPT_NZ_VIS_CHK Use 0 Const
Check if there is a nozzle in the ANC pocket before placing the nozzle.
0: It does not check.
1: It checks.
64
System
OPT_ANC_SHUTTER Use 0 Const
Use the function to minimize the Open/Close movement of the ANC
shutter when getting the nozzle.
0: Not user
1: use
25
SYS_DELAY_ANC Use 200 msec The delayed time after the sense of the ANC sensor.
26
NZ_GET_DN_MARGIN Use 1200 um
he further amount of the down movement of the head when it moves
down to pick the nozzle.
90
NZ_EXIST_CHK_METHOD Use 1 Const
Set the method to check the existence of the nozzle.
0: Use the nozzle check sensor if it is CP45 and use pneumatic pressure
if it is CP55 or SM320(SM321).
1: Use the binary pixel count function that uses the vision system.
91
Factory
NZ_VIS_USE_CHK_VALUE Reserved 30 %
When checking the existence of the nozzle by using the vision system,
set the criteria for the nozzle existence check to white pixel 30%.
36
METHOD_VIS_NZ_CHK Use 1
Option for the recognition method for the vision system when checking
the existence of the nozzle by using the vision system.
0: Individual recognition method
1: Simultaneous recognition method
50
IGNORE_NOZ_CHK_SENSOR Use 0 0 , 1
When the nozzle check sensor has a problem, if this value is set to 1,
the sensor does not check the nozzle.
53
VIS_NZ_CHK_DELAY_TIME Use 50 msec
Time delay constant necessary for simultaneous recognition when
checking the nozzle existence by using the vision system.
ANC
58
Debug
ANC_SPEED_OPTI Use 1 const
Set the LookAhead function.
0: Not set, 1: Set
