Softwar e Module No Constant Name Classification Va l u e Unit Description 71 OPT_HRS_VISION Use 0 Const 0: The HRS function is not used, 1: Use the HRS function. 62 SYS_FL Y_OUTER_LEVEL Use 0 Const Set the control algor…

100%1 / 245
Software
Module
No
Constant Name Classification
Value
Unit Description
69
SYS_HEAD_VAC_METHOD Use 34 Const
Add each value of the method related to the vacuum control.
1: Check the Open Level at each cycle.
2: Check the Open Level whenever ANC is performed.
8: Check the Open Level only when performing the Vac Check (Pick
Check).
16: Check for the nozzle clogging at each cycle.
32: Check for the nozzle clogging each time a part is dumped.
71
SYS_Z_OFFSET_VAC Use 40 um
The difference between the actual value and the measurement value of
the Z-axis height when it is measured using the vacuum.
The difference of the value when inserting the CN040 in the nozzle-
holder.
74
PICK_TEACH_VAC_METHOD Reserved 0 Const
Set whether to compensate the hei
g
ht b
y
usin
g
the vacuum for the small
part when a retry (Pickup) error occurred. (1: Use , 0: Not Use)
75
PICK_TEACH_VAC_DIST Reserved 0 um
When usin
g
the pickup position compensation function usin
g
the
vacuum, the difference between the measured value and the
compensated value.
96
VAC_CLOSE_DETECT_ABS Use 600 mmHg
The absolute value for the criteria for the nozzle clogging (used for the Z
offset).
97
VAC_CLOSE_DETECT_DIFF Use 60 mmHg
The difference value for the criteria for the nozzle clogging (used for the
Z offset).
47
Debug SKIP_VAC_SENSOR_ADJ Use 0 0 , 1 0: Adjust and check the VAC sensor in Auto mode. 1: Not checked.
46
OPT_HEAT_SENSOR_TERM Use 0 msec
0: Not used. Inform the operator of the heat sensor detection at the input
cycle.
47
OPT_AREA_SENSOR Use 0 Const 0: The area sensor is not used, 1: Use the area sensor.
48
OPT_BYPASS_SW_TIME Use 600
sec 0: Not used. Inform the bypass state at the input cycle.
Safety
49
System
OPT_BYPASS_SW_DOOR Use 0 Const
0: Check all the doors with only one ByPass key of the machine.
1: There is a ByPass key for each door. Check the front door.
2: There is a ByPass key for each door. Check the rear door.
3: There is a ByPass key for each door. Check the front and rear door.
Align /
Mount
50
System
OPT_MFOV_NO_Z_UP Use 0 Const
0: When performing split recognition(MFOV), the Z axis moves down
during XY movement.
1: When performing split recognition(MFOV) , the Z axis does not move
down during XY movement.
Software
Module
No
Constant Name Classification
Value
Unit Description
71
OPT_HRS_VISION Use 0 Const 0: The HRS function is not used, 1: Use the HRS function.
62
SYS_FLY_OUTER_LEVEL Use 0 Const Set the control algorithm of the outer illumination for the fly-camera.
68
SMALL_COMP_METHOD Use 15 Const Method related to the small component.
70
SMALL_COMP_SIZE Use 650 um The reference size of the small component.
72
VERY_SMALL_COMP_METHOD Use 7 Const Method related to the very small component.
73
VERY_SMALL_COMP_SIZE Use 400 um The reference size of the very small component.
94
Factory
FLY_INSPR_METHOD Use 3 Const
0: The fly camera performs recognition after rotation (recognition by
placement angle).
1: The fly camera rotates after recognition (recognition of 0 degrees).
2: The fly camera rotates after recognition. However, it performs
recognition after rotation at the feeding angle of 45 degrees and during
fine grabbing.
3: The fly camera rotates after recognition. However, it performs
recognition after rotation at the feeding angle of 45 degrees and during
fine grabbing and fine pitch feeding.
28
MOUNT_POS_CHECK_METHOD Use 0
The function that checks the position of the place stopper before
placement.
0: No check.
1: The placement stopper is at the right of the front side.
2: The placement stopper is at the left of the front side.
3: The placement stopper is at the right of the rear side.
4: The placement stopper is at the left of the rear side.
30
SUPPORT_GRAB_AND_MO
VE
Use 1
Determine whether to use the method that grabs the part
and immediately starts moving it when using the fix-
camera.
0: Move after recognition.
1: Move after GRAB.
33
Debug
SUPPORT_FIX_SYNC_GRA
B
Use 1
Determine whether to use the simultaneous grabbing
method by using 2 fix cameras.
0: No simultaneous grabbing, 1: Simultaneous grabbing
Software
Module
No
Constant Name Classification
Value
Unit Description
34
SUPPORT_MOUNT_OPTI Use 1
Determine whether to use the placement option through which
the part is placed in a different order. (Pick , Align, Mount…)
0: Not used. 1: Use.
35
METHOD_MOUNT_OPTI Use 4
The option for the method to set the placement order.
51
USE_FLY_AUTOTEACH_RA
NGE
Use 0 0, 1
1: Use the value of FLY_AUTOTEACH_RANGE (#52) as
the recognition range when performing automatic teaching
(applicable only for fly camera).
0: Perform recognition on the entire screen.
52
FLY_AUTOTEACH_RANGE Use 0 um
Refer to No.51
60
SUPPORT_SMART_PROFIL
E
Use 95 const Supports smart profile algorism.
62
FLY_CONST_TIME Use 25 msec
Time to last the constant speed(XY speed) during
recognition by the fly camera.
63
FLY_DECSTART_TIME Use 90 msec
Time which the speed(XY speed) begin to be reduced
during recognition by the fly camera.
69
SUPPORT_SMART_SEQ Use 1 Const Supports the smart seq algorism.
16
READY_RELAY_DELAY Reserved 800 msec
The time delay from the time the Ready Relay is turned on
until it is checked.
0: Apply default value (approximately 150msec).
Others: According to the set value
17
USE_UPS Use 0 Const
0: UPS is not used.
1: Use the UPS.
H/W
18
Factory
CE_TYPE Use 0 Const
0: Not applied (the CE type).
1: Applied (the CE type)
