Software
5. Click <Parameter> button in the ‘Window meun’ dialog box.
Caution
Do not click any button in the ‘Window menu’ dialog box.
6. Select <Read-out from the amplifier> option button in the ‘Selection of parameter to
be read’ dialog box and click <OK> button.
7. The following screen shows the connection to the driver is normal.
.
Software
5.2.5.4. Changing setting value
Warning
Without any permission of out company, agencies or users
can not change parameter. We are not liable for faults of
machine caused by failure to observe this.
1. Select the parameter to be changed on communication with the amplifier. And then,
change the parameter in the <Setting value> combo box and click <Change of the
setting value> button .
Software
2. To download to driver, click “Trans” Icon and “EEP” Icon to change ROM value in
the driver.
3. Turn off the machine power and then turn on it again. Then, new parameter is applied
to the driver normally.
5.2.5.5. Downloading the specified file to the driver
Warning
Our company provide the specified parameters by each
driver(The driver parameter for Spare Part is downloaded
to the driver in our company before it is forwarded to
users).
1. In order to download Parameter to the driver, perform the procedures ‘5.2.5.2 The
connection between panasonic driver and computer‘ and ‘5.2.5.3 Software
execution‘ and then read the parameter of the driver.
Caution
Back up the parameters saved in the existing driver. The
standard parameters of the manufacturer are saved in the
new driver. However, they may be changed for tuning in
our factory.
2. If closing “Parameter(Read-out from the amplifier)” window, return to the “Window
Menu” state.
