AHB01ESPP
1.2.4 Menus for Data Editing
••
••
• Menu Selection
1. When the [DATA EDIT] button on the main menu bar is pressed, the
"EDIT SEL." menu opens.
2. Select the desired option from the "EDIT SEL." menu. The corre-
sponding window opens separately.
3. Select the data to be edited. The corresponding edit window opens.
Fig. 2D10 Selection of Menus for Data Editing
1.2 Using the Menus
0308-004 4-10
"Pattern Program" Edit Window
"Component Library" Edit Window
AHB01ESPP
••
••
• Composition of Menus for Data Editing
The following edit windows can be opened by selecting the menus for
data editing.
Refer to "2.1" in "Section 4" for the tabs and tab sheets.
"DATA EDIT" Menu
"EDIT SEL." Menu
PATT. PRGM.
"Pattern Program Edit" Selection Window
Select the desired program name and press the [Edit Prgm] or the [Create
New] button.
"Pattern Program" Edit Window
Tabs Tabs Reference No.
Operation Data P.C.B. Data "Section 2" in "Vol. 3"
P.C.B. Recognition Data
P.C.B. Recognition Mark Data
Setup Data
Placement Feeder Feeder Base #1
Location
Feeder Base #3
Feeder Base #4
Tray #2 F701-F799
Tray #2 F801-F899
Tray #2 STEP
FB #3 VIB Feeder 1
FB #3 VIB Feeder 2
FB #3 VIB Feeder 3
FB #4 VIB Feeder 1
FB #4 VIB Feeder 2
FB #4 VIB Feeder 3
(To the next page)
Fig. 2D11 Composition of Menus for Data Editing (1)
The above tree structure is based on the selection of the multi-
layer tray feeder (option).
01 12-002 4-11
1.2 Using the Menus
(To the next page)
Note
AHB01ESPP
(From the previous page)
Placement Data U01
P Data
O Data
U02
P Data
O Data
CMPNT. LBRY.
"Selection of component ID" Window
Select the desired component ID and press the [Open] button.
"Component Library" Edit Window
Tabs Tabs Reference No.
Shape Data Mold Size "
Section 3" in "Vol. 3"
Corner Data
Edge Data
Linear Edge Data
Lead Data
Electrical Contact Data
Recognition Data
Control Data
Carrier Data
Fig. 2D11-1 Composition of Menus for Data Editing (2)
1.2 Using the Menus
01 12-002 4-12
