AHB01ESPP 3 . 3 "Opn. Mode" T ab The corresponding tab sheet enables the operator to specify various operation modes such as "Recovery Mode", "Auto. Fdr . Axis Set", "PCB Counter Stop M…
AHB01ESPP
(a) When "Disable" is specified for the alternated feeder mode,
the "Altn Fdr Mode" tab sheet looks as follows.
Fig. 2E11 "Altn Fdr Mode" Tab Sheet (Alternate Feeder Mode: Disable)
(b) The parameters specified here become valid prior to the
other alternate-related ones that are designated in the pat-
tern program.
Even when "Enable" is set in the pattern program, this al-
ternate feeder mode (function) can be used to temporarily
set "Disable" in relation to preparation for the feeders.
(c) The set parameters ("Enable" or "Disable" (alternate feeder
modes) for each individual feeders) are saved when the
[POWER ON] or the [POWER OFF] button is pressed,
the system is cleared, or the current pattern program data
is modified.
3.2 "Altn Fdr Mode" Tab
0206-001 5-14-3
Note
AHB01ESPP
3.3 "Opn. Mode" Tab
The corresponding tab sheet enables the operator to specify various
operation modes such as "Recovery Mode", "Auto. Fdr. Axis Set", "PCB
Counter Stop Mode", etc.
• Sheet Layout
When the "Opn. Mode" tab is pressed in the "OPN. MODE" window
(submenu), the following tab sheet appears inside the window.
Fig. 2E12 "Opn. Mode" Tab Sheet (Provided with Multi-Layer Tray Feeder 2)
The tab sheet may look different, depending on which options
are selected.
• Sheet Composition
*1 Recovery Mode
It can be determined in which mode "Stop Auto Run" or "Priority Of
Comp." the machine should be set when a component shortage
error is detected.
[Stop Auto Run] Button
When a component shortage error is detected, the machine stops
running immediately.
3.3 "Opn. Mode" Tab
0206-003 5-15
*5
*3
*2
*1
*4
*6
Note
AHB01ESPP
[Priority Of Comp.] Button
When a component shortage error is detected, the machine does
not stop immediately.
Although a message is issued as machine information to prompt
the operator to replenish components, the machine keeps on plac-
ing the other components.
The machine places all remaining components on a P.C.B. and stops
running without discharging the P.C.B.
Relation between Recovery Mode and Alternate Function
(1) "Priority Of Comp." Selected
• The alternate function is not activated immediately for the
pertinent placement step (step for which the recovery
function should be implemented) after a pick-up or a com-
ponent shortage error, etc., is detected.
• The alternate function is activated after the machine has
placed the component in the last step specified in the
pattern program data.
(2) "Priority Of Comp." Not Selected
The alternate function is activated immediately after a com-
ponent shortage error (including the process specified in
"Error process 1" and "Error process 2" in the component
library data) is detected.
0206-003 5-16
3.3 "Opn. Mode" Tab
