Section 1

Scope

This section describes mainly the outline of the machine

such as the features and specifications.

0308-002 1-A AHB01ESPP

0107-001 1-B AHB01ESPP

1. Features

This machine is capable of recognizing various types of electrical com-

ponents and precisely place them on a P.C.B.

This latest and multi-functional mounter is provided with advanced tech-

nologies such as small and light multi-heads, a fly nozzle change func-

tion, a fly recognition function, and X/Y-axis linear motor driving and

equipped with easy-to-operate user interfaces, making it possible to

maintain high total productivity.

Table 2A1

New Mechanism Features

X/Y-Axis Linear Motor • Y-Axis Twin Driving System

Driving • X/Y Beam High-Speed Movement

• Long-Term Maintenance-Free Structure

Multi-Heads • Small and Light Servomotors

• Highly Accurate Placement Angle (Z) Correction

• Simultaneous Pick-Up Enabled by Independent Driving Heads

(not restricted by feeder pitches)

Fly Nozzle Change • Nozzle Change Function Implemented during Head Movement

Function

Fly Recognition Function • Component Recognition Performed during Head Movement

Highly Accurate Image • Highly Accurate Image Recognition System

Recognition Function • Stabilization of Component Pick-Up and Placement by Real

Time Automatic Correction

New Mobile Tape Feeder • Attachment/Detachment Possible during Automatic Operation

• LED Flashing (Warning) at Component Shortage

User Interfaces • Programs based on Windows 2000

• Improvement of Operativeness (Combination of Touch Screen

and Keyboard/Pointing Device)

• High-Speed Data Communication on Ethernet Network
