AHB01ESPP
• Procedure for Component Recognition Test
The following methods are provided to conduct a component recog-
nition test.
• Component Recognition Test on Manually Attached Component
• Component Recognition Test on Automatically Picked Component
from Each Feeder
The following describes how to use each method.
Procedure for Component Recognition Test on Manually Attached
Component
A component cannot be attached manually on the front side of
the machine.
Be sure to attach a component manually on the rear side of the
machine.
(1) Press the [Test ID] button (*4) in the "Component Recog. Test" sheet
(Fig. 2F22). The "Test ID Set" sheet appears.
Register the component ID to be tested as a test ID.
(2) Check the parameter in the text box (*6) and attach the specified
nozzle.
Attach the nozzle in the "Nozzle Set/Reset" sheet.
Refer to "4.4 "Nozzle Change" Tab" for details.
(3) Press the [Fdr. No.] button (*5). The "Fdr. No." sheet appears.
Set the feeder No. so that the installed feeder is not located at the
position where it does not set in the way of manual component at-
tachment.
In normal cases, the [Front Ctr] button should be selected.
(4) Press the button (*2). The sheet appears.
Select the head that is provided with the nozzles on the operation
side.
(5) Press the button (*3). The sheet appears.
Select the camera to capture an image.
(6) Press the button (*9). The sheet appears.
Select the [ON] button to use the function.
(7) Select the [Vacuum Pick-Up Off] button in the "Vac Valve" group box
(*10).
(The vacuum valve is turned "ON" automatically.)
When the vacuum valve is kept "ON" (component pickup
condition), the previous sheet cannot be resumed.
(8) Press the [Pick from Fdr (Mnl)] button and then the [ON] button (en-
titled "MOVE"). After that, press the [ENABLE] button on the opera-
tion panel in 2 seconds.
The head moves to the position of the specified feeder No. and the
vacuum valve is turned "ON" automatically.
(9) Set the [OPERATION] switch on the operation panel to the "SETUP"
side.
Note
0206-003 6-41
3.3 "Cmpnt Recog Test" Tab
Note
Note
AHB01ESPP
(10) Press the [READY] button on the operation panel. The LED extin-
guishes.
(11) Open the safety door and manually attach a component to the cen-
ter of the nozzle.
(12) Press the [READY] button. The LED illuminates.
(13) Set the [OPERATION] switch on the operation panel to the "RUN"
side.
(14) Press the [Move to Recog Sta & Recog (Full Auto)] button and
then the [ON] button (entitled "MOVE"). After that, press the [EN-
ABLE] button on the operation panel in 2 seconds.
A component recognition test is conducted.
(15) Check the results of the recognition in the "Result of Recog Test"
group box (*8).
• When the results of the recognition are normal, proceed to Step
(17).
• When the results of the recognition are not normal, proceed to
Step (16).
(16) After that, conduct the component recognition test again.
(17) Make a hysteresis test.
Refer to "3.3.2 Hysteresis Test" for details.
(18) Press the [Comp. Collection] button and then the [ON] button (en-
titled "MOVE"). After that, press the [ENABLE] button on the opera-
tion panel in 2 seconds.
Components are collected (discharged) and the X/Y beam is ze-
roed.
Components are discharged to the nearest component storage
box or the recycle conveyor (option).
To collect components manually, follow the steps below to
send the components to the pick-up position and collect
them.
(1) Press the [Pick from Fdr (Mnl)] button and then the [ON] button (en-
titled "MOVE"). After that, press the [ENABLE] button on the opera-
tion panel in 2 seconds.
(2) Set the [OPERATION] switch on the operation panel to the "SETUP"
side.
Press the [READY] button on the operation panel. The LED extin-
guishes
(3) Open the safety door and manually attach a component to the cen-
ter of the nozzle.
(4) Press the [READY] button. The LED illuminates.
(5) Set the [OPERATION] switch on the operation panel to the "RUN"
side.
(6) Press the [Comp. Collection] button to perform the function and zero
the X/Y beam.
Note
0206-003 6-42
3.3 "Cmpnt Recog Test" Tab
AHB01ESPP
Procedure for Component Recognition Test on Components
Picked Automatically from Each Feeder
(1) Press the [Test ID] button (*4) in the "Component Recog. Test" tab
sheet (Fig. 2F22). The "Test ID Set" sheet appears.
Register the component ID to be tested as a test ID.
(2) Check the parameter in the text box (*6) and attach the specified
nozzle.
Attach the nozzle in the "Nozzle Set/Reset" sheet.
Refer to "4.4 "Nozzle Change" Tab" for details.
(3) Replenish the feeders for the production model with components.
Refer to the instruction manual of the tape and vibratory stick feed-
ers for details.
(4) Press the [Fdr. No.] button (*5). The "Fdr. No." sheet appears.
Set the same component ID (feeder No.) as the specified test ID.
(5) Press the button (*2). The sheet appears.
Select the head that is provided with the nozzles on the operation
side.
(6) Press the button (*3). The sheet appears.
Select the camera to capture an image.
(7) Press the button (*9). The sheet appears.
Select the [ON] button to use the function.
(8) Select the [Vacuum Pick-Up Off] button in the "Vac Valve" group box
(*10).
(The vacuum valve is turned "ON" automatically.)
When the vacuum valve is kept "ON" (component pickup
condition), the previous sheet cannot be resumed.
(9) Press the [Pick from Fdr (Auto)] button and then the [ON] button
(entitled "MOVE"). After that, press the [ENABLE] button on the op-
eration panel in 2 seconds.
The head moves to the position of the specified feeder No. and the
components are picked up.
(10) Press the [Move to Recog Sta & Recog (Full Auto)] button and
then the [ON] button (entitled "MOVE"). After that, press the [EN-
ABLE] button on the operation panel in 2 seconds.
A component recognition test is conducted.
(11) As for the following operations, refer to Steps (15) through (18)
described in "Procedure for Component Recognition Test on Manu-
ally Attached Component" for details.
Note
0206-003 6-43
3.3 "Cmpnt Recog Test" Tab
