AHB01ESPP
Table 2F8
Tabs Description
Head Rotation Ofs The corresponding tab sheet enables the operator to
perform the teaching operation on the head rotation
offset data.
(Prepared only for service personnel)
Cmpnt Recog Mvbl Mag The corresponding tab sheet enables the operator to
perform the teaching operation on the magnification
offset of the component recognition camera (movable).
(Prepared only for service personnel)
Cmpnt Recog Mvbl Camr Ofs The corresponding tab sheet enables the operator to
perform the teaching operation on the offset data of the
component recognition camera (movable). (Prepared
only for service personnel)
Nozzle Stocker Ofs The corresponding tab sheet enables the operator to
perform the teaching operation on the nozzle stocker
offset data.
(Prepared only for service personnel)
Nozzle Stocker Ofs The corresponding tab sheet enables the operator to
perform a teaching operation on the nozzle stocker
offsets. (Prepared only for service personnel)
Feeder Base Ofs The corresponding tab sheet enables the operator to
perform the teaching operation on the feeder base off-
set data.
(Prepared only for service personnel)
Feeder (A) Ofs The corresponding tab sheet enables the operator to
perform the teaching operation on the feeder (A) offset
data.
(Prepared only for service personnel)
Feeder (B) Offset The corresponding tab sheet enables the operator to
perform the teaching operation on the feeder (B) offset
data.
Teaching Plate Ofs The corresponding tab sheet enables the operator to
perform the teaching operation on the teaching plate
offset data.
(Prepared only for service personnel)
Nozzle Center Ofs The corresponding tab sheet enables the operator to
perform the teaching operation on the nozzle center
offset data.
Nozzle Tip Pos Ofs The corresponding tab sheet enables the operator to
perform a teaching operation on the nozzle tip position
offset data. (Prepared only for service personnel)
5. "TEACHING" Window (Submenu)
0308-004 6-79
AHB01ESPP
Table 2F9
Tabs Description
Head Master Offset The corresponding tab sheet enables the operator to
perform a teaching operation on the head master off-
set data. (Prepared only for service personnel)
Traverse Ofs This is an optional function.
Refer to the instruction manual of the multi-layer tray
feeders for details.
Lighting Teach The corresponding tab sheet makes it possible to
teach various kinds of lighting-related parameters.
(Prepared only for service personnel)
• The accuracy of component placement is affected by the
teaching operations. Only our service personnel or a trained
one shall perform teaching operations.
• Some operations require special jigs (optional).
Consult our service personnel before performing any teach-
ing operations.
• Follow the teaching procedures in the specified order. Other-
wise, some trouble (such as inaccurate component place-
ment, frequent mechanical errors, etc.) will arise.
• Before performing the teaching operation, check that the
component recognition offset jig, the jig location, and the
back light stage (teaching plate) are not nicked nor stained.
Refer to "Periodic Maintenance" in "Vol. 4: Maintenance and
Troubleshooting" for details.
0308-004 6-80
5. "TEACHING" Window (Submenu)
CAUTION
AHB01ESPP
• Basic Teaching Procedure
The teaching operations must be performed on the following items in
the described order.
(1) P.E.C. Recog Camr & Beam Ofs
(2) Table Ofs
(3) NC-Axis Ofs
(4) Cmpnt Fxd Camr Mag
(5) Cmpnt Recog Fxd Camr Ofs
(4) Head Height Offset (Manual Operation)
Obtain the height offset data of each head (all six nozzles) through
manual operation and register them in the "Up/down L (mm)" text
boxes of the "Device Offset 2" tab sheet. (Operation Sequence:
[SYSTEM] Button on Main Menu Æ "SYS DATA" Menu Æ "Machine
System Data" Window Æ "Offset Data" Tab Æ "Device Offset" Tab
Æ "Device Offset 2" Tab)
Refer to "2.1.1 "Device Offset" Tab" in "Section 5" of "Vol. 3: Pro-
gramming and Machine Data" for details.
(5) Teaching Plate Offset
(6) Magnification of Component Recognition Camera (Fixed)
(7) Offset of Component Recognition Camera (Fixed)
(8) Head Center Offset
(9) Nozzle Stocker Offset
(10) Head Rotation Offset
(11) Magnification of Component Recognition Camera (Movable)
(12) Offset of Component Recognition Camera (Movable)
The above-described offset items are related to the accuracy of com-
ponent placement.
Perform the following teaching operations after the above-described off-
set items.
(13) Feeder Base Offset
(14) Feeder (A) Offset
(15) Nozzle Center Offset
(16) Traverse Offset (Option)
• When the "P.E.C. Dsbl." and "Comp. Recognition
Dsbl." check boxes are turned on (checked), the
related teaching operations cannot be performed
correctly.
Be sure to turn off the check boxes in the "Test Run"
tab sheet.
• Be sure to press the [End] button after each teach-
ing operation. Otherwise, the results will not be re-
flected.
To exit from each teaching operation without saving
the results, press the [Cancel] button.
To make the results ineffective, press the [Clear Adj.]
button.
0308-004 6-81
5. "TEACHING" Window (Submenu)
CAUTION
