SIPLACE BulkFeeder X / Operating Manual 05/2017 Edition
11
2 System Requirements and Compatibility
The following requirements and compatibility apply for the SIPLACE BulkFeeder X:
● The following machine configuration exists in the field and has to be retrofitted.
Placement machine Retrofit kit Item no.
X-Series S
BulkFeeder X retrofit kit XSeries S
00141650-xx
SX-Series
BulkFeeder X retrofit kit SX
00141660-xx
Figure 2-1: Existing machine configuration
● A separate SIPLACE Vision computer is required for each placement machine. This is a
427d I7 computer equipped with a 4x GigE interface card and the cabling to connect the
SIPLACE BulkFeeder X and the computer.
The SIPLACE Vision software for the SIPLACE BulkFeeder X has to be installed on the
SIPLACE Vision computer. Information can be found in the Station Software Installation
Manual, item no.: [00198001-xx]
● Software requirements:
Station software: Version 710.1 or higher
SIPLACE Pro: Version 14.1 or higher
ASM Setup Center: Version 9.1 or higher
● Supported tables: COT60 and COT40
The SIPLACE BulkFeeder X is designed as a standard X-Feeder and occupies 3 tracks.
Therefore, it can be set up on every changeover table, docking station or other tools designed
for X-Feeders.
● Supported placement heads: C&P20 A, C&P20 P
2.1 Restrictions
– COT30 table is not supported.
– X-series placement machines with hardware ID < 6 of the FCU are not supported. However,
with the Upgrade Kit (DTC FCU) it is possible to upgrade the machine to ID >=6.
– No combination with MTC / WPC / linear feeders / stick feeders at one table.
– Station software 60x is not supported.
– No combination with the Coplan option.
SIPLACE BulkFeeder X / Operating Manual 05/2017 Edition
12
3 SIPLACE BulkFeeder X – Functionality
The SIPLACE Bulkfeeder X [00141630-xx] consists of the following two main modules:
● SIPLACE BulkFeeder X Base Unit, item no: [00141600-xx]
● SIPLACE BulkFeeder X Cartridge, item no: [00141602-xx]
In the following, these modules are referred to as Base Unit and Cartridge respectively.
3.1 Base Unit
Figure 3-1: Base Unit
1. Cartridge 5. Mechanical mount
2. Handle 6. Camera, electronics, vibration unit
3. Control panel 7. Slide bars
4. Locking mechanism 8. RFID
The Base Unit of the SIPLACE BulkFeeder X looks similar to an SmartFeeder X and is just as easy
to install on the feeder table.
The Base Unit carries all active parts like optics, mechanics and electronics and occupies 3 tracks.
It has an EDIF (energy and data interface) on the 1
st
track and a second light conductor on the 3
rd
track. Additionally, it is equipped with a connector for the camera cable.
SIPLACE BulkFeeder X / Operating Manual 05/2017 Edition
13
3.2 Cartridge
Figure 3-2: Cartridge
1. Pickup plate (glass plate) with plate shutter
2. Component container with container shutter (filled with components)
3. Refill connector
4. Clamping mechanism
5. RFID
The Cartridge SIPLACE BulkFeeder X consists of the pickup plate with pickup area and plate
shutter, the component container with container shutter and the filling funnel.
The Cartridge gets inserted on the Base Unit via a guide rail and can be easily replaced while the
feeder stays on the table. The Cartridge has a separate locking system and can be removed by
pressing the yellow button on the feeder for at least 1 second or under Manual Operations on the
station software GUI.
The components are picked up contactlessly from the glass plate. The surface of the glass plate is
structured to avoid that the components adhere.
WARNING
Do not touch the glass plate. ►
Each Cartridge has a unique ID that is stored at the bottom side of the Cartridge. Additionally, the
same ID is printed as barcode on the Cartridge. Thus, the Cartridge can be uniquely identified
either via the RFID or the barcode by ASM Setup Center.
Within the field of view of the feeder camera there are two through-holes with a diameter of 1 mm
as fiducials for SIPLACE Vision in the Cartridge.
