A-89 A39-1 台車本体 -1 Trolley unit - 1 3 4 5 5 5 6 5 7 1 5 1 2 1 3 1 9 2 0 2 1 2 1 2 0 2 7 2 6 2 6 2 7 2 3 2 4 2 8 2 9 3 0 3 0 2 2 3 1 3 3 3 3 6 3 5 3 5 3 6 3 6 3 2 3 7 3 8 3 8 3 9 1 8 2 5 4 3 4 3 4 2 5 4 4 4 4 5 4 4 4 5 4 …

100%1 / 226
A-88
A38
電源トランス
Power unit
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1
EZ1-445-159-11 TRANSFORMER, POWER (TH6500U16KC) ﾃﾞﾝｹﾞﾝ ﾄﾗﾝｽ(TH6500U16KC) 1 POWER UNIT(208V)
EZ1-445-159-11 TRANSFORMER, POWER (TH6500U16KC) ﾃﾞﾝｹﾞﾝ ﾄﾗﾝｽ(TH6500U16KC) 1 POWER UNIT(220V)
EZ1-445-159-11 TRANSFORMER, POWER (TH6500U16KC) ﾃﾞﾝｹﾞﾝ ﾄﾗﾝｽ(TH6500U16KC) 1 POWER UNIT(230V)
EZ1-445-159-11 TRANSFORMER, POWER (TH6500U16KC)
ﾃﾞﾝｹﾞﾝ ﾄﾗﾝｽ(TH6500U16KC)
1 POWER UNIT(240V)
EZ1-445-160-11 TRANSFORMER, POWER (TH6500EKC)
ﾃﾞﾝｹﾞﾝ ﾄﾗﾝｽ(TH6500EKC)
1 POWER UNIT(380V)
EZ1-445-160-11 TRANSFORMER, POWER (TH6500EKC)
ﾃﾞﾝｹﾞﾝ ﾄﾗﾝｽ(TH6500EKC)
1 POWER UNIT(400V)
EZ1-445-160-11 TRANSFORMER, POWER (TH6500EKC) ﾃﾞﾝｹﾞﾝ ﾄﾗﾝｽ(TH6500EKC) 1 POWER UNIT(415V)
EZ1-445-160-11 TRANSFORMER, POWER (TH6500EKC) ﾃﾞﾝｹﾞﾝ ﾄﾗﾝｽ(TH6500EKC) 1 POWER UNIT(430V)
2 EZ7-683-472-04 BOLT,HEXAGON SOCKET 8X16 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 8X16 4
3 EZ7-688-007-12 W 8 MIDDLE
W 8 MIDDLE
4
A-89
A39-1
台車本体 -1
Trolley unit - 1
3 4
5 5
5 6
5 7
1 5
1 2
1 3
1 9
2 0
2 1
2 1
2 0
2 7
2 6
2 6
2 7
2 3
2 4
2 8
2 9
3 0
3 0
2 2
3 1
3 3
3 3
6
3 5
3 5
3 6
3 6
3 2
3 7
3 8
3 8
3 9
1 8
2 5
4 3
4 3
4 2
5 4
4 4
4 5
4 4
4 5
4 6
4 7
4 6
4 7
4 8
4 8
6 1
6 2
6 0
6 4
6 5
6 5
6 1
6 0
6 2
6 3
6 3
5 9
5 9
6 6
6 7
6 7
6 3
6 0
6 0
6 1
6 3
6 4
6 5
6 0
6 5
6 0
6 7
6 0
6 6
6 2
6 0
6 7
6 1
6 3
6 1
6 1
6 3
6 1
6 1
5 8
7 1
7 1
A
A
7 6
7 4
7 5
7 7
7 7
7 2
7 3
B
B
C
3 3
3 3
3 4
5
1 7
7 8
1 6
5 2
1 4
1 1
5 3
C
1 2
5 0
5 1
4 9
6 9
7 0
6 8
6
1 0
1 0
9
7
8
7
9
8
4 0 4 1
A-90
A39-1
台車本体 -1
Trolley unit - 1
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-43572 TROLEY_STAND ﾄﾛﾘｰｽﾀﾝﾄﾞ 1
2 401-45946 TROLEY_STAND_950 ﾄﾛﾘｰｽﾀﾝﾄﾞ_950 1 950MM 仕様
3 401-43573 STAND_BASE_ASSY ｽﾀﾝﾄﾞﾍﾞｰｽｱｯｼｰ (1)
4 401-45945 STAND_BASE_ASSY_950
ｽﾀﾝﾄﾞﾍﾞｰｽｱｯｼｰ_950
(1)
950MM 仕様
5 401-53358 STAND_BASE
ｽﾀﾝﾄﾞﾍﾞｰｽ
(1)
6 401-43493 CASTER
ｷｬｽﾀｰ
(4)
7 SL6-08209 SCREW M8 L=20 座金付き六角穴ﾎﾞﾙﾄ M8 L=20 (16)
8 WS-0820002-KN SPRING WASHER M8 ﾊﾞﾈｻﾞｶﾞﾈ M8 (16) 950MM 仕様
9 WP-0841601-SC WASHER 8.4X17.4X1.6 ﾋﾗｻﾞｶﾞﾈ ﾐｶﾞｷﾏﾙ M8 (16) 950MM 仕様
10 401-45947 CASTER_SPASER
ｷｬｽﾀｰｽﾍﾟｰｻｰ
(4)
950MM 仕様
11 401-43575 HANDLE_R_ASSY
ﾊﾝﾄﾞﾙ R ｱｯｼｰ
(1)
12 401-62284 HANDLE_BASE_R
ﾊﾝﾄﾞﾙﾍﾞｰｽ R
(1)
13 401-27991 TROLLEY_HANDLE ﾄﾛﾘﾊﾝﾄﾞﾙ (1)
14 E2641-729-000 HANDLE CLIP ﾊﾝﾄﾞﾙｸﾞﾘｯﾌﾟ (1)
15 SL-6082592-TN SCREW M8 L=25 座金付き六角穴ﾎﾞﾙﾄ M8 L=25 (3)
16 401-43576 STAND_SIDE_BASE_L_ASSY
ｽﾀﾝﾄﾞｻｲﾄﾞﾍﾞｰｽ L ｱｯｼｰ
(1)
17 401-43496 STAND_SIDE_BASE_L
ｽﾀﾝﾄﾞｻｲﾄﾞﾍﾞｰｽ L
(1)
18 401-43497 SLIDE_RAIL
ｽﾗｲﾄﾞﾚｰﾙ
(1)
19 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
20 400-89239 E_TROLLEY_PLATE E ﾄﾛﾘｰﾌﾟﾚｰﾄ (2)
21 SM-3061052-TN SCREW M6 L=10 ﾏﾙﾈｼﾞ M6 L=10 (2)
22 401-43577 STAND_SIDE_BASE_R_ASSY
ｽﾀﾝﾄﾞｻｲﾄﾞﾍﾞｰｽ R ｱｯｼｰ
(1)
23 401-43498 STAND_SIDE_BASE_R
ｽﾀﾝﾄﾞｻｲﾄﾞﾍﾞｰｽ R
(1)
24 401-43497 SLIDE_RAIL
ｽﾗｲﾄﾞﾚｰﾙ
(1)
25 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (4)
26 400-89239 E_TROLLEY_PLATE E ﾄﾛﾘｰﾌﾟﾚｰﾄ (2)
27 SM-3061052-TN SCREW M6 L=10 ﾏﾙﾈｼﾞ M6 L=10 (2)
28 HX-0015000-00 CABLE CLAMP
ｹｰﾌﾞﾙｸﾘｯﾌﾟ
(1)
29 WT-0430002-KN WASHER M4
ﾊﾂｷｻﾞｶﾞﾈ M4
(1)
30 SM-6040802-TN SCREW M4X0.7 L=8
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ M4X0.7 L=8
(2)
31 401-43499 REEL_HOLDER_SUPPORT_L ﾘｰﾙﾎﾙﾀﾞｻﾎﾟｰﾄ L (1)
32 401-43500 REEL_HOLDER_SUPPORT_R ﾘｰﾙﾎﾙﾀﾞｻﾎﾟｰﾄ R (1)
33 SM-3051052-TN SCREW M5 L=10 ﾏﾙﾈｼﾞ M5 L=10 (10)
34 SM-6051002-TN SCREW
ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ
(4)
35 SL-6061692-TN SCREW M6 L=16
座金付き六角穴ﾎﾞﾙﾄ M6 L=16
(8)
36 SL-6061092-TN SCREW M6 L=10
座金付き六角穴ﾎﾞﾙﾄ M6 L=10
(2)
37 401-43501 FRONT_COVER_BOTTOM ﾌﾛﾝﾄｶﾊﾞｰﾎﾞﾄﾑ (1)
38 SM-6051002-TN SCREW ﾛｯｶｸｱﾅ ﾎﾞﾙﾄ (2)
39 SM-3051052-TN SCREW M5 L=10 ﾏﾙﾈｼﾞ M5 L=10 (2)
40 401-64481 FRONT_COVER
ﾌﾛﾝﾄｶﾊﾞｰ
(1)
41 401-43502 FRONT_PLATE
ﾌﾛﾝﾄﾌﾟﾚｰﾄ
(1)
42 401-43503 BACK_PLATE
ﾊﾞｯｸﾌﾟﾚｰﾄ
(1)
43 SM-3040552-TN SCREW M4 L=5 丸ねじ M4 L=5 (4)
44 E2711-721-000 TROLLEY STOPPER ﾄﾛﾘｰｽﾄｯﾊﾟｰ (2)
45 SL-6061292-TN SCREW M6 L=12 座金付き六角穴ﾎﾞﾙﾄ M6 L=12 (4)
46 401-43504 GROUND_CHAIN
ｸﾞﾗｳﾝﾄﾞﾁｪｰﾝ
(2)
47 SM-3061252-TN SCREW M6 L=12
ﾏﾙﾈｼﾞ M6 L=12
(2)
48 401-43505 SUPPORT_SP
ｻﾎﾟｰﾄｽﾌﾟﾘﾝｸﾞ
(2)
49 401-64219 TAPE_GUARD_F_S ﾃｰﾌﾟｶﾞｰﾄﾞ F_S (1)
50 HM-0010100-1B FAN MOTOR ﾌｨﾙﾀｰ (1)
51 SL-4040881-SC SCREW M4 L=8 ｻﾞｶﾞﾈﾂｷ ﾅﾍﾞｺﾈｼﾞ M4 L=8 (4)
52 SM-3051052-TN SCREW M5 L=10
ﾏﾙﾈｼﾞ M5 L=10
(6)
53 401-43574 HANDLE_L_ASSY
ﾊﾝﾄﾞﾙ L ｱｯｼｰ
(1)
54 401-62283 HANDLE_BASE_L
ﾊﾝﾄﾞﾙﾍﾞｰｽ L
(1)
