A-100 A 42 CVS ユニット CVS UNIT 8 9 3 2 4 4 5 5 6 6 1 3 1 2 1 0 1 0 1 0 1 1 1 0 1 4 1 6 1 5 2 1 1 5 1 6 1 7 1 8 1 8 1 9 2 0 7 1 2 4 2 5 2 6 2 7 2 8 2 9 3 0 2 2 3 1 3 2 3 3 3 5 3 6 3 7 3 8 3 9 4 0 4 6 5 5 5 4 6 0 5 4 5 5 5 3…
A-99
A41
梱包添付品
Accessories
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-44555 EF ARRANGE CBL BLACKET ASM EF ARRANGE CBL BLACKET ASM 1
2 EZ1-846-577-12 CABLE BEFORE AND BEHIDN I/F 前後 I/F ｹｰﾌﾞﾙ 1
3 EZ4-454-592-01 DUST CAP (DL-P-D/C) ﾀﾞｽﾄ ｷｬｯﾌﾟ (DL-P-D/C) 2
4 EZ4-456-308-01 SHEET (S) FOOT
ｱｼ ﾖｳ ｼ-ﾄ (S)
2
5 EZ4-456-309-01 BRACKET JOINT
ﾚﾝｹﾂ ﾌﾞﾗｹｯﾄ
2
6 EZ4-761-958-01 SHEET (LEG)
ｱｼ ﾖｳ ｼ-ﾄ
4
7 EZ4-761-962-01 CAP BOLT (CP-30-BC-20) ﾎﾞﾙﾄ ｷﾔﾂﾌﾟ (CP-30-BC-20) 4
8 EZ7-683-473-04 BOLT HEXAGON SOCKET 8X20 6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 8X20 8
9 EZ7-688-007-12 W8 MIDDLE W8 MIDDLE 8
10 EZ1-845-148-11 MEMORY USB
USB ﾒﾓﾘ (USM4GR B)
1
11 401-46085 RX-7 INSTRUCTION MANUAL(ST)
RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(ST)
1
12 401-46086 RX-7 INSTRUCTION MANUAL(EN)
RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(EN)
1
13 401-46087 RX-7 INSTRUCTION MANUAL(CH) RX-7 ﾄﾘｱﾂｶｲｾﾂﾒｲｼｮ(CH) 1
A-100
A42
CVS ユニット
CVS UNIT
8
9
3
2
4
4
5
5
6
6
1 3
1 2
1 0
1 0
1 0
1 1
1 0
1 4
1 6
1 5
2 1
1 5
1 6
1 7
1 8
1 8
1 9
2 0
7
1
2 4
2 5
2 6
2 7
2 8
2 9
3 0
2 2
3 1
3 2
3 3 3 5
3 6 3 7
3 8
3 9
4 0
4 6
5 5
5 4
6 0
5 4
5 5
5 3
6 0
4 9
5 0
4 9
4 9
4 9
5 1
5 2
4 5
4 5
4 4
4 4
4 3
4 3
4 1
4 2
4 8
4 7
6 9
6 8
6 7
5 8
5 7
5 7
5 6
5 9
6 2
6 3
6 4
6 5
6 6
6 1
7 0
2 3
3 9
A
A
2 1
A-101
A42
ＣＶＳユニット
CVS UNIT
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 401-54477 CVS PROBE UNIT(R) CVS PROBE UNIT(R) 1
2 401-53441 CVS_BR_A CVS_ﾌﾞﾗｹｯﾄ A (1)
3 400-94686 INSULATION_SHEET ｲﾝｼｭﾚｰｼｮﾝｼｰﾄ (1)
4 400-94688 CVS_WASHER
CVS_ﾜｯｼｬｰ
(4)
5 401-42109 BUSH
BUSH
(4)
6 401-03174 SPRING_0.34N
SPRING_0.34N
(2)
7 EZ7-300-011-84 BUSHING UNIVERSAL(GEE62F-A-C)
ｼﾞｻﾞｲ ﾌﾞﾂｼﾕ (GEE62F-A-C)30.48M
(0.04)
8 401-03176 CONTACT_BASE_A CONTACT_BASE_A (1)
9 401-03177 CONTACT_BASE_B CONTACT_BASE_B (1)
10 401-03178 CONTACT_SH
CONTACT_SH
(4)
11 SL-4030681-SC SCREW M3 L=6
座金付きなべ小ねじ M3 L=6
(2)
12 401-03180 CVS CONTACT CABLE(+) ASM
CVS ｺﾝﾀｸﾄｹｰﾌﾞﾙ(+)ｸﾐ
(1)
13 401-05380 CVS CONTACT CABLE(-) ASM CVS ｺﾝﾀｸﾄｹｰﾌﾞﾙ(-)ｸﾐ (1)
14 SL-4031281-SC SCREW M3 L=12 座金付きなべ小ねじ M3 L=12 (2)
15 WS-0310002-KN SPRING WASHER M3 ﾊﾞﾈｻﾞｶﾞﾈ M3 (2)
16 NM-6030001-SC NUT M3X0.5 TYPE1
六角ﾅｯﾄ M3X0.5 1 種
(2)
17 401-53442 CVS_BR_B_R
CVS_ﾌﾞﾗｹｯﾄ B_R
(1)
18 SL-6030592-TN SCREW M3 L=5
座金付き六角穴ボルト M3 L=5
(3)
19 SL-6030592-TN SCREW M3 L=5 座金付き六角穴ボルト M3 L=5 (1)
20 SL-6041092-TN SCREW M4 L=10 座金付き六角穴ボルト M4 L=10 (2)
21 401-54486 CVS PROBE CABLE ASM CVS PROBE CABLE ASM 1
22 401-54473 CVS_PWB_UNIT_R
CVS_基板ﾕﾆｯﾄ R
1
23 401-53444 CVS_PWB_BR_R
CVS_基板ﾌﾞﾗｹｯﾄ_R
(1)
24 400-95117 CVS PCB ASM
CVS 基板組
(1)
25 HX-0035400-00 SPACER スペーサ (6)
26 401-53446 CVS_PWB_COVER CVS_基板ｶﾊﾞｰ (1)
27 SL-6030592-TN SCREW M3 L=5 座金付き六角穴ボルト M3 L=5 (6)
28 401-53448 GUIDE_ROLLER_DR-30-H6W1
ｶﾞｲﾄﾞﾛｰﾗ_DR-30H61W
(2)
29 SL-6063092-TN SCREW M6 L=30
座金付き六角穴ボルト M6 L=30
(2)
30 WP-0641600-SC WASHEW 6.4X12.5X1.6
ﾋﾗｻﾞｶﾞﾈ
(4)
31 401-53447 CVS_CABLE_BR CVS_ｹｰﾌﾞﾙﾌﾞﾗｹｯﾄ 1
32 EZ4-457-931-11 TAPE(40) FIXED ｺﾃｲ ﾃ-ﾌﾟ(40) 2
33 EZ4-716-434-11 TIE INSULOCK(AB100 BLACK) ｲﾝｼﾕﾛﾂｸ ﾀｲ(AB100 ｸﾛ) 8
34 EZ4-716-434-21 TIE INSULOCK (AB150 BLACK)
ｲﾝｼﾕﾛﾂｸ ﾀｲ (AB150 ｸﾛ)
6
35 EZ4-716-434-31 TIE INSULOCK (AB200 BLACK)
ｲﾝｼﾕﾛﾂｸ ﾀｲ (AB200 ｸﾛ)
12
36 EZ7-300-011-85 BUSHING UNIVERSAL(GEE99F-A-C)
ｼﾞｻﾞｲ ﾌﾞﾂｼﾕ (GEE99F-A-C)30.48M
0.61
37 EZ7-300-011-84 BUSHING UNIVERSAL(GEE62F-A-C)
ｼﾞｻﾞｲ ﾌﾞﾂｼﾕ (GEE62F-A-C)30.48M
0.08
38 HX-0070600-0A MOUNT BASE ﾏｳﾝﾄﾍﾞｰｽ 4
39 SL-6051092-TN SCREW M5 L=10 座金付き六角穴ボルト M5 L=10 4
40 401-54478 CVS PROBE UNIT(L)
CVS PROBE UNIT(L)
1
41 401-53441 CVS_BR_A
CVS_ﾌﾞﾗｹｯﾄ A
(1)
42 400-94686 INSULATION_SHEET
ｲﾝｼｭﾚｰｼｮﾝｼｰﾄ
(1)
43 400-94688 CVS_WASHER CVS_ﾜｯｼｬｰ (4)
44 401-42109 BUSH BUSH (4)
45 401-03174 SPRING_0.34N SPRING_0.34N (2)
46 EZ7-300-011-84 BUSHING UNIVERSAL(GEE62F-A-C)
ｼﾞｻﾞｲ ﾌﾞﾂｼﾕ (GEE62F-A-C)30.48M
(0.04)
47 401-03176 CONTACT_BASE_A
CONTACT_BASE_A
(1)
48 401-03177 CONTACT_BASE_B
CONTACT_BASE_B
(1)
49 401-03178 CONTACT_SH CONTACT_SH (4)
50 SL-4030681-SC SCREW M3 L=6 座金付きなべ小ねじ M3 L=6 (2)
51 401-03180 CVS CONTACT CABLE(+) ASM CVS ｺﾝﾀｸﾄｹｰﾌﾞﾙ(+)ｸﾐ (1)
52 401-05380 CVS CONTACT CABLE(-) ASM
CVS ｺﾝﾀｸﾄｹｰﾌﾞﾙ(-)ｸﾐ
(1)
53 SL-4031281-SC SCREW M3 L=12
座金付きなべ小ねじ M3 L=12
(2)
54 WS-0310002-KN SPRING WASHER M3
ﾊﾞﾈｻﾞｶﾞﾈ M3
(2)
