A -34 A1 5 ヘッド ASSY-6 Head assy - 6 ｲﾗｽﾄ番号 Ref.No. 品番 Part Number Description 品名 個数 Q'ty 備考 Remarks 49 EZ4 - 457 - 070 - 01 RT GEA R SPRING RT ｷﾞｱ ｽﾌﾟﾘﾝｸﾞ 5 50 EZ4 - 462 - 448 - 01 SPCER RT GEAR RT ｷﾞｱ ﾖｳ ｽﾍﾟ - ｻ 5 …

100%1 / 226
A-33
A15
ヘッド ASSY-6
Head assy - 6
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
1 EZ4-454-045-01 FINE U NUT ﾌｱｲﾝ U ﾅﾂﾄ (FU-00SUS) 1
2 EZ4-456-867-01 BOLT (SSH) HEXAGON SOCKET ﾛﾂｶｸ ｱﾅﾂｷ ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ (SSH) 5
3 EZ3-272-056-01 BALL (DIA. 1.2) STEEL ｽﾁ-ﾙ ﾎﾞ-ﾙ (ﾌｱｲ 1.2) 32
4 EZ3-279-059-02 SPRING (O RING -D#) O RING
ﾉｽﾞﾙ O ﾘﾝｸﾞ ﾊﾞﾈ (O ﾘﾝｸﾞ -D*)
16
5 401-82117 RESIN SCREW(M2X6)
ｼﾞｭｼﾈｼﾞ(M2X6)
32
6 EZ3-703-358-52 PIN PARALLEL (DIA. 2X6)
ﾍｲｺｳﾋﾟﾝ (ﾌｱｲ 2X6)
16
7 EZ3-854-267-01 FLANGELESS BALL BEARING ﾎﾞ-ﾙﾍﾞｱﾘﾝｸﾞ(6800ZZ) 2
8 EZ4-453-914-01 NOZZLE DRIVE GEAR (TAPER) ﾉｽﾞﾙ ｸﾄﾞｳ ｷﾞｱ 1
9 EZ4-453-915-01 COLLAR INNER ｲﾝﾅ- ｶﾗ- 1
10 EZ4-453-916-01 MANIFOLD ROTARY
ﾛ-ﾀﾘ- ﾏﾆﾎ-ﾙﾄﾞ
1
11 EZ4-453-917-01 GEAR RT (MAIN)
ｷﾞｱ-RT (ﾒｲﾝ)
1
12 EZ4-453-918-01 GEAR RT (SUB)
ｷﾞｱ-RT (ｻﾌﾞ)
1
13 EZ4-453-919-01 GEAR RN (MAIN) ｷﾞｱ-RN (ﾒｲﾝ) 1
14 EZ4-453-920-01 GEARM RN (SUB) ｷﾞｱ-RN (ｻﾌﾞ) 1
15 EZ4-453-923-01 SHAFT MAIN ﾒｲﾝ ｼﾔﾌﾄ 1
16 EZ4-453-924-01 RN IDLE GEAR SHAFT
RN ｱｲﾄﾞﾙ ｷﾞｱ ｼﾔﾌﾄ
1
17 EZ4-453-926-01 WASHER SPACER
ｽﾍﾟ-ｻ
1
18 EZ4-453-927-01 WASHER U NUT
U ﾅﾂﾄ ﾜﾂｼﾔ
1
19 401-76158 RETAINER(1)_SPRING ﾊﾞﾈｳｹ(1) 16
20 401-76159 BUSHING_SPRING RETAINER ﾊﾞﾈｳｹﾌﾞｯｼｭ 16
21 EZ4-454-003-02 RETAINERM PIN ﾋﾟﾝ ｵｻｴ 16
22 EZ4-454-004-01 SPRING COMPRESSION(DIA2.4X6.2)
ｱﾂｼﾕｸ ｺｲﾙ ﾊﾞﾈ (ﾌｱｲ 2.4X6.2)
16
23 EZ4-454-005-01 PIECE (DIA1.2X1.6)
ｾﾂﾄ ﾋﾟ-ｽ (ﾌｱｲ 1.2X1.6)
32
24 401-79294 PIN_DIA0.86
ﾋﾟﾝ(DIA0.8x6)
16
25 401-95260 JOINT COUPLING2 ｶｯﾌﾟﾘﾝｸﾞｼﾞｮｲﾝﾄ 2 16
26
EZ4-454-025-01 SOCKET UPPER GEAR (B) ｳｴ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (B) 2 INDEX 2,10
EZ4-454-025-11 SOCKET UPPER GEAR (D) ｳｴ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (D) 2 INDEX 4,12
EZ4-454-025-21 SOCKET UPPER GEAR (F)
ｳｴ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (F)
2 INDEX 6,14
EZ4-454-025-31 SOCKET UPPER GEAR (H)
ｳｴ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (H)
2 INDEX 8,16
27
EZ4-454-026-01 SOCKET GEAR LOWER (A)
ｼﾀ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (A)
2 INDEX 1,9
EZ4-454-026-11 SOCKET GEAR LOWER (C) ｼﾀ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (C) 2 INDEX 3,11
EZ4-454-026-21 SOCKET GEAR LOWER (E) ｼﾀ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (E) 2 INDEX 5,13
EZ4-454-026-31 SOCKET GEAR LOWER (G) ｼﾀ ﾊｸﾞﾙﾏ ｿｹﾂﾄ (G) 2 INDEX 7,15
28 EZ4-454-032-01 SPACER GEAR
ｷﾞｱﾖｳ ｽﾍﾟ-ｻ-
5
29 EZ4-454-033-01 NZ GEAR SPACER
ﾉｽﾞﾙ ｷﾞｱ ｽﾍﾟ-ｻ
8
30 EZ4-454-034-05 NUT BEARING
ﾍﾞｱﾘﾝｸﾞ ﾅﾂﾄ
16
31 EZ4-454-042-01 NOZZLE GEAR ﾉｽﾞﾙ ｷﾞｱ 16
32 EZ4-454-043-01 NZ SHAFT HOLDER ﾉｽﾞﾙ ｼﾔﾌﾄ ﾎﾙﾀﾞ- 16
33 EZ4-454-045-01 FINE U NUT ﾌｱｲﾝ U ﾅﾂﾄ (FU-00SUS) 1
34 EZ4-454-049-02 NZ SHAFT (LTS4CSS+91.5LPF)
ﾉｽﾞﾙ ｼﾔﾌﾄ (LTS4CSS+91.5LPF)
16
35 EZ4-454-056-01 O RING (S10)
O ﾘﾝｸﾞ (S10)
2
36 EZ4-454-057-01 O RING (SS-080)
O ﾘﾝｸﾞ (SS-080)
2
37 EZ4-454-075-01 MINIATURE Y PACKING MYA-15 ﾐﾆ Y ﾊﾟﾂｷﾝ (MYA-15) 2
38 EZ4-454-081-01 SHAFT S064B ｼﾔﾌﾄ S062B 32
39 EZ4-454-082-01 BOLT (SNZS-M1.4X3) ｾｲﾐﾂｷｷﾖｳ ﾅﾍﾞｺﾈｼﾞ (SNZS-M1.4X3) 16
40 EZ4-454-746-02 HOLDER (2) SPRING
ﾊﾞﾈ ｳｹ (2)
16
41 EZ4-454-752-01 MECHANICAL VALVE
ﾒｶﾆｶﾙ ﾊﾞﾙﾌﾞ
16
42 EZ4-454-757-01 O RING (S8)
O ﾘﾝｸﾞ (S8)
1
43 EZ4-454-758-02 NZ SHAFT SPRING ﾉｽﾞﾙ ｼﾔﾌﾄ ｽﾌﾟﾘﾝｸﾞ 16
44 EZ4-454-769-01 KEY PARALLEL (R03006) ﾍｲｺｳ ｷ- (R03006) 1
45 EZ4-454-770-01 KEY PARALLEL (R03008) ﾍｲｺｳ ｷ- (R03008) 1
46 EZ4-454-771-01 SNAP RING SHAFT (8)
ｼﾞｸﾖｳ C ｶﾞﾀ ﾄﾒﾜ (8)
1
47 EZ4-456-867-01 BOLT (SSH) HEXAGON SOCKET
ﾛﾂｶｸ ｱﾅﾂｷ ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ (SSH)
5
48 EZ4-457-069-01 RT GEAR SPRING POST
RT ｷﾞｱ ﾊﾞﾈ ﾎﾟｽﾄ
5
A-34
A15
ヘッド ASSY-6
Head assy - 6
ｲﾗｽﾄ番号
Ref.No.
品番
Part Number
Description
品名
個数
Q'ty
備考
Remarks
49 EZ4-457-070-01 RT GEAR SPRING RT ｷﾞｱ ｽﾌﾟﾘﾝｸﾞ 5
50 EZ4-462-448-01 SPCER RT GEAR RT ｷﾞｱ ﾖｳ ｽﾍﾟ- ｻ 5
51 EZ4-535-343-01 RN GEAR SPRING RN ｷﾞｱ ｽﾌﾟﾘﾝｸﾞ 5
52 EZ4-719-038-21 BEARING (MR148ZZ)
ﾍﾞｱﾘﾝｸﾞ (MR148ZZ)
1
53 EZ7-683-404-04 BOLT HEXAGON SOCKET 3X8
6 ｶｸｱﾅﾂｷﾎﾞﾙﾄ 3X8
6
54 EZ4-484-927-01 LOW HEAD SCREW (M3X12)
ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ (M3X12)
6
55 401-84269 BEARING(MR106T12DDMC2P5D8SX) ﾍﾞｱﾘﾝｸﾞ(MR106T12DDMC2P5D8SX) 32
56 401-84276 SHAFT HOLDER BEARING COLLAR(1) ｼｬﾌﾄﾎﾙﾀﾞｰﾍﾞｱﾘﾝｸﾞｶﾗｰ(1) 16
57 EZ4-454-000-01 HEAD TURRET ﾀﾚﾂﾄ ﾍﾂﾄ 1
58 401-63249 FILTER (RX-7 S16)
ﾌｨﾙﾀｰ (RX-7 S16)
16
