EDM V2.2 / User Guide Ausgabe 10/2013 Edition

All changed sub-objects for which changes are pending in the Clearing Pool are displayed in a

confirmation window. Only the selected, tagged objects will be restored.

Figure 4-10: Confirming objects to be restored

► Confirm your selection by clicking OK.

The selected objects are restored on the Line Server and the changes are removed from the

Clearing Pool.

4.2.2 Transferring the Change Notifications to the EDM Master

All change notifications are transferred to the EDM Master after a configurable timeout has elapsed

(see EDM Installation Manual). Notifications can be sent immediately by clicking Send Pending

Notifications in the EDM Client:

Figure 4-11: Sending pending notifications

4.2.3 "Auto Reject" and "Direct Import"

Data which matches the rules for Auto Reject and Direct Import is not put into the Clearing Pool.

In the case of Direct Import, the data is transferred directly to the EDM Master database, and in

the case of Auto Reject the data is ignored. Therefore, it is not necessary to enter comments at

the EDM Line in this case.

Further information about this can be found in section 5.1.7.

EDM V2.2 / User Guide Ausgabe 10/2013 Edition

4.3 EDM Data Transfer Manager (Push Mode)

The Data Transfer Manager allows users to send defined data packages to Line Servers.

The Data Transfer Manager opens in the selection view when it is started (either from the

Windows® Start menu: Programs - SIPLACE EDM - EDM Data Transfer (Push) or from the

shortcut on the desktop).

4.3.1 Creating a Data Package

Figure 4-12: Creating a data package

The Transfer data to line (Push) button is disabled by default: .

The red error icon to the right shows that the user still has to make entries. Details are displayed as

a tooltip or if the user left-clicks on the error indicator.

The following steps are necessary to successfully transfer objects to a line. It is recommended that

you initially follow the sequence given.

By clicking on the error icon a new dialog window opens displaying the messages.

EDM V2.2 / User Guide Ausgabe 10/2013 Edition

4.3.1.1 Selecting an Application Template

If a template has previously been selected in an earlier session of the Data Transfer Manager, this

is preselected in the drop-down list. This drop-down list contains all the templates stored in the

selected template folder.

► Select a template from the drop-down list or click the button to select another template

folder.

4.3.1.2 Selecting the Line(s)

Once a template has been selected, the Line Server drop-down list shows all the known lines

selected by the template. The following icons indicate the status of the line. Further details are

displayed in the tool tip for the icon and in the Status field of the Line Server drop-down list.

Icon Meaning

The Line Server is available and can receive data packages.

The Clearing Pool contains unprocessed entries for this line. The entries in the Clearing

Pool should be checked and removed before data is sent to this Line Server. Nevertheless,

it is possible to push data.

The Clearing Pool contains unprocessed entries for this line. One of these objects in the

Clearing Pool has been added to the Object selection list. The object must be removed

from the Clearing Pool or the Object selection list or the line must be deactivated in the

Line Server drop-down list before data can be sent to this Line Server.

Something is wrong on the Line Server. The EDM Tool may not be running.

The Line Server is not responding, does not exist (incorrect entry in the EDM configuration

file), the EDM service is not running on the Line Server, or push mode is not enabled

there.

The SIPLACE Pro versions are not compatible with each other.

The activated functions do not match each other.

Example: the conflict detection is active but no SPI line is configured.

Table 4-1: Icons for line status

The associated check box at the beginning of the row must be checked to transfer objects to a Line

Server. The All (all Line Servers shown), Valid and None buttons check or uncheck the check

boxes of the relevant Line Server groups.
