EDM V2.2 / User Guide Ausgabe 10/2013 Edition

default log4net.config

log4net_debug.config

Contain the EDM logging configuration for normal and debug

output.

Note: If you want to change the logging of all lines - that share

a configuration set - simply, replace the "Log4Net"

configuration set entry with the reference to the new logging

configuration (e.g. log4net_debug.config) and transfer the

changes to the affected lines.

workflows clientWorkflow.xml Contains the standard EDM Workflow used by the EDM Client

during the "Pull" operation. The files just moved from the root

configuration folder to the 'workflows'' folder.

Table 6-5: List of the EDM configuration files

Manual configuration upgrade

EDM 2.x will try to convert the essential settings during the installation.

If you want to manually upgrade a configuration from EDM 1.x to 2.x you may try use:

"EdmPsc.exe upgrade src [dst]" ('src' specifies the folder containing the old EDM 1.x

config; 'dst' is the destination folder for the new EDM 2.x configuration (if omitted the source folder

will also be used as destination folder).

In EDM 2.x, EdmPsc.exe also creates an "EDM 2.x" compatibility configuration.

All EDM configuration files are XML-based files. The SystemConfig.xml and CustromSettings.xml

files use the format of the Microsoft Dictionary Configuration-Sections

(<add key="x" value="y" />).

The default EDM configuration files found in the defaultconfiguration directory of the EDM Setup

folder contain placeholders that are changed during installation - They thus cannot be used to

restore the standard configuration (at least not without additional modifications).

NOTICE

► Create a backup of the existing configuration before you make any manual changes!

EDM V2.2 / User Guide Ausgabe 10/2013 Edition

6.2.1 Configuration Sets

An EDM Configuration Set has a configuration type of

"Siemens.SiplacePro.EDM.Common.Configuration.ConfigurationSet" and contains a

list of configuration files associated with the configuration set. EDM uses 15 standard entries,

custom configuration files (e.g. used in workflows) may be added as needed. All files referenced in

the configuration set must be stored in the EDM configuration directory (or any sub-folder except

"_cache"). The default configuration set (used by the configuration server or in local mode) is

named "EdmConfiguration.xml" and has to reside in the EDM Configuration folder.

Name Default Type

MachineConfig

global\MachineConfig.xml ….Common.Configuration.MachineConfig

RoleConfig

global\RoleConfig.xml ….Common.Configuration.RoleConfig

SystemConfig

default\SystemConfig.xml ….Common.Configuration.SystemConfig

CommentConfig

default\CommentConfig.xml ….Common.Configuration.CommentConfig

CustomConfig

default\CustomConfig.xml ….Common.Configuration.CustomConfig

RequestConfig

default\RequestConfig.xml ….Common.Configuration.RequestConfig

DataTransferConfig

default\DataTransferConfig.xml ....DataTransferExtension.PushModeConfig

Rules

default\NotificationFilterConfig.xml ...Common.NotificationFilterConfig

Rules_DirectImport

default\ClearingPoolImportFilterConfig.xml ....Common.NotificationFilterConfig

Rules_AutoReject

default\ClearingPoolRejectFilterConfig.xml ….Common.NotificationFilterConfig

EmailFilter

default\EmailNotificationFilterConfig.xml ….Common.NotificationFilterConfig

EmailSettings

default\EmailConfig.xml (EDM EmailConfig)

DisplayConversionConfig

default\DisplayConversionConfig.xml (Generic XML)

Log4Net

default\log4net_debug.config (Log4Net)

NotificationDisplay notifications\NotificationDisplayTemplates.r

esx

EDM User Language customized messages

ClientWorkflow

workflows\clientWorkflow.xml (EDM Workflow)

Table 6-6: Standard EDM Configuration Set entries

"…": refers to Siemens.SiplacePro.EDM

NOTICE

The paths to the configuration files are relative to the location of the configuration set!

EDM V2.2 / User Guide Ausgabe 10/2013 Edition

6.2.2 Machine Configuration

The Machine Configuration consists of a "<machines>" section containing a list of "<host>"

entries. Each entry has the following attributes:

● id (DNS-Name)

● alias (EDM-Display-Name)

● serverType (the type of the EDM installation, generally "LINE")

● xmlHandling Flag

(See 6.2.6.29 for a description of the possible values. The default is "-1" which means

"ByServerType" and results in "1" for Lines and "9" for the Master)

Each host entry may also contain a list of <spiLine> child elements with the 'path' attribute

specifying the SIPLACE Pro path of the associated Line. The special values "[ALL]" and "[NONE]"

may also be used to indicate, that a host shall be assigned to all or no line. If no entry is found,

EDM assumes that it is assigned to all lines found in the local SIPLACE Pro installation.

Please remember, that an EDM Line Alias must meet the following criteria:

1. It must be unique

2. It must not be equal to the "id" of another entry (it may be equal to its own id though)

3. It may not be empty or consist of only whitespace characters (spaces tabs etc.)

4. It should not contain new lines

The "id" (hostname) has to fulfil these criteria:

1. It must be unique

2. It must not be equal to the "alias" of another entry (it may be equal to its own alias though)

3. It may not be empty or consist of only whitespace characters (spaces tabs etc.)

4. It cannot contain new lines

5. Only hostnames are allowed (EDM will not resolve IP-Addresses)

A sample Machine-Config file:

<configurationInfo name="Demo" version="2.0.0.0" comment="Sample Configuration"

type="Siemens.SiplacePro.EDM.Common.Configuration.MachineConfig"/>

</host>

</machines>

</configuration>
