6 Product / Package Form User’s Manual Line Computer UNIX
6.1 Package Form Editor Software Version 403.xx Edition 06/97
6 - 14
6.1.2.6 Display Area - Setting "Vision data"
The current package form is graphically represented in the display area. When the dimensions are edited in
the "Nominal dimensions" and "Body" editing areas, the display is automatically updated.
-
The package (body) is drawn as a rectangle with a solid black line.
-
The two rectangles drawn with a broken black line reflect the nominal dimensions including negative
and positive tolerance values. (The nominal dimensions themselves are not displayed).
-
Created pin models are depicted as filled dark-blue rectangles in accordance with their length and
width dimensions. Their color changes depending on their state (see color explanation below).
-
Created ball models are depicted as filled dark-blue circles in accordance with their diameters. Their
color changes depending on their state.
Explanation of colors
Dark-blue pin/ball --> non-selected group for which a model is defined.
Gray-blue pin/ball --> non
-selected group for which no model has been defined yet.
Dark-green pin/ball --> selected group for which a model is defined.
Light-green pin/ball --> selected group for which no
model has been defined yet.
Single-click on a pin or a ball with the color
dark-blue or gray-blue --> draws a black frame around the group to which the clicked-on object
belongs.
The pins/balls contained in the selected group are displayed in
dark-green or light-green.
All pins/balls contained in the non-selected groups for which the same
model was defined, are displayed in dark-green.
Single-click on a pin or a ball with the color
dark-green or light-green --> reverses the selection
NOTE
For the windows required for changing group or model data to open, the clicking sequence described below
must be observed.
Opening the window for changing group data
●
Single-click on any pin (see Fig. 6.1.1) or ball (see Fig. 6.1.3) of the desired group.
The whole group is highlighted.
●
Select pin or ball once more by (quickly) double-clicking.
The window for editing the group data is opened (see Fig. 6.1.16).
User’s Manual Line Computer UNIX 6 Product / Package Form
Software Version 403.xx Edition 06/97 6.1 Package Form Editor
6 - 15
Opening the window for entering or changing model data
●
Select desired pin or ball by (quickly) double-clicking.
The window for editing the model data is opened (see Fig. 6.1.17 and Fig. 6.1.22).
NOTE
The window for editing the group or model data can also be opened using the commands "Group"
or "Pin/Ball" (see section 6.1.2.4).
6 Product / Package Form User’s Manual Line Computer UNIX
6.1 Package Form Editor Software Version 403.xx Edition 06/97
6 - 16
6.1.2.7 Package Form Editor Selection Fields - "Handling data" Display
In the selection fields a button is located next to each "handling type" (see Fig. 6.1.4).
The required "handling type" can be activated or deactivated by clicking on the corresponding button.
Selection field "Handling instructions"
This field serves to define the type of handling a component type will be subjected to during the placement
cycle.
-
Vacuum test during pick-up When the component is picked up sensors are used to
check whether the component has been picked up.
-
Vacuum test during placement Prior to being placed, the component is interrogated by means
of sensors to verify that the component is still attached to the
nozzle.
-
Coplanarity check The coplanarity laser module determines by means of co-
planarity measurement whether pins of the component
are bent and whether it may have to be discarded.
-
Good nozzle contact In the case of cubic components, this setting provides
good nozzle contact by means of adequate vacuum supply.
Selection field "Centering"
This selection field serves to define the type of centering suited for the component type. For this purpose, the
setting "Centering in head" or "External centering" can be chosen from. Moreover, the centering procedure for
the particular centering type can be defined.
- Centering in head
The component is centered by means of the revolver head or the
placement head on the HS-180 if any one of the following three
options is selected in addition.
with H jaws mech. centering by means of h-jaws (measuring jaws) of the
placement head of the HS-180.
with Z jaws mech. centering by means of z-jaws of the placement head of
the HS-180.
with camera optical centering by means of the component camera of the
revolver head.
