User’s Manual Line Computer UNIX 8 Product / PCB
Software Version 403.xx Edition 06/97 8.1 PCB Editor
8 - 39
-
Mirror-inverting PP positions about the x-axis
The signs of all values entered in the editing area under "Y" (placement positions in y-direction) are
reversed.
●
Click on
EDIT
-->
Mirror-inverting placement positions about the X-axis.
All positive values entered (prior to the above clicking action) under "Y" are now displayed with a
negative sign preceding the entries, all previous negative values are now displayed as positive values.
-
Mirror-inverting PP positions about the Y-axis
The signs of all values entered in the editing area under "X" (placement positions in x-direction) are
reversed.
●
Click on
EDIT
-->
Mirror-inverting placement positions about the Y-axis.
8.1.6.2 SERVICES Menu
-
Opening the
Cluster Editor
●
Click on
SERVICES
-->
Cluster Editor
.
The window of the Cluster Editor is opened (see Fig. 8.1.8).
-
Opening new
Structure Editor
●
Click on
SERVICES
-->
Structure Editor...
.
The FSB for the selection of a new PCB is opened (see page 8 - 6).
●
Select PCB and confirm with
OK
.
The structure of the selected PCB is displayed in the display area of the newly opened window.
8.1.6.3 Editing Area of the Placement Position Editor
INPUT POSSIBILITIES:
-
Comp. name
name of the component (max. 11 characters)
-
X, Y
placement position in x and y-directions (referred to the PCB zero point);
it is possible to enter 3 decimal places before and 3 decimal places behind
the decimal point.
-
angle
angle at which component is placed during placement operation (-360° to
+360°) referred to the PCB coordinate system; it is possible to enter 3
decimal places before and 2 decimal places behind the decimal point.
-
bkdns
scheduling the processing sequence (process-specific data);
b = placing, k = gluing, d = dispensing (solder paste metering),
n = reworking, (must be entered in combination with "b", "k" or "d".
However, it must not be combined with "s")
s = blocking (must be entered in combination with "b", "k" or "d".
However, it must not be combined with "n")
8 Product / PCB User’s Manual Line Computer UNIX
8.1 PCB Editor Software Version 403.xx Edition 06/97
8 - 40
-
lev.
Number of the placement level (number between 1 ... 9999)
NOTE
If, for example, components of extremely varying heights are to be placed very closely next to one
another, it is necessary to define a placement sequence with the aid of placement levels in order to
avoid problems during the placement process. However, at present such a placement sequence is
only defined with respect to components that need to be placed with the IC head.
The level numbers entered determine the sequence in which the placement positions will be pro-
cessed. The placements will be processed in accordance with the level numbers, in an ascending
order.
Placement positions that were assigned the same level, will be processed within that level in any
order whatever.
Placement positions that were not assigned any specific level may be processed at any level.
- Max. 9999 placement levels can be assigned.
- Every placement position can be assigned one level.
- Any one level can be assigned several placement positions.
- The levels do not need to be numbered consecutively.
-
fiducial set
Name of fiducial set (max. 11 characters; # = no fiducial set)
-
Comment
freely selectable, e.g. component type
PROCEDURE to be followed for editing
:
-
Editing
●
Position mouse cursor in the editing area and make entries from the keyboard.
A space must be left between entries of individual columns.
●
Finish the completed input line with
RETURN
.
●
After completing the entries, click on the icon in the command area (see Fig. 8.1.11).
The individual entries are now checked and placed in the corresponding columns.
If an incorrect entry has been made, the entire editing area is surrounded by a red frame and an
error message is displayed on the screen.
●
If applicable, confirm the error message by clicking on
OK
.
The dialog box is closed and the cursor is automatically positioned, within the editing area, at the
location of the incorrect entry.
-
Copying entries
in the Placement Position Editor within one and the same window or to another open
Placement Position Editor window.
●
Hold down the left mouse button and move the mouse cursor over the entries to be copied (exa-
ctly to the end of the last character) and then release the mouse button.
The lines concerned now darken.
●
Hold down the center mouse button and position the cursor to the position in the editing area of
the respective window of the Placement Position Editor where the lines are to be inserted and
then release the mouse button.
The copied entries are now displayed.
User’s Manual Line Computer UNIX 8 Product / PCB
Software Version 403.xx Edition 06/97 8.1 PCB Editor
8 - 41
8.1.6.4 Command Area of Placement Position Editor
-
Check PP data
If you click on this icon following the editing of the PP data, all data entered in the editing area will be
checked for correctness (e.g. number of positions before and after the comma, number of characters,
etc.) and arranged in the various columns provided.
-
Search/Replace
This button serves to open the window for the entry of search or replacement texts. In the editing fields
of this window any character strings desired can be entered which will subsequently be searched for
or replaced, respectively.
●
Click on the in the command area.
The search window for the entry of a search or replacement text is opened.
Fig. 8.1.12 Search Window "Placement Position Editor"
Setting area
The conditions for the search or replacement operation are defined in the setting area with the aid of various
buttons.
Setting possibilities for the search/replacement operations within the given text:
-
Search/replace from cursor position downward Searching/replacing is performed within
the current placement program from the
cursor position in downward direction
-
Search/replace from cursor position upward Searching/replacing is performed within
the current placement program from the
cursor position in upward direction
editing fields
command area
setting area
