User’s Manual Line Computer UNIX 17.3 Description of Components and PCBs
Software Version 403.xx Edition 06/97 17.3.3 PCB 3: Focus on Cluster Technique
17 - 47
Defining ink spot:
no ink spot is present.
To create a single circuit in a cluster, proceed as follows:
42. Activate the Create icon .
43. Click on the cluster, here:
pattern_1
.
A dialog box is opened.
44. Click on the editing field.
45. Enter the name for the single circuit, here:
board_1,
and click on the
OK
button.
The dialog box is closed. The new single circuit is displayed at the third level.
To enter the offset values for the single circuit, proceed as follows:
46. Activate the Coordinate system icon .
47. Click on the single circuit, here:
board_1
.
A dialog box is opened.
48. Click on the individual editing fields and enter the offset values, see
Fig. 17.3.7
on page 17-
41
.
49. Click on the
OK
button.
The dialog box is closed.
To load the cluster data and placement positions of another PCB for the single circuit:
50. Activate the Select icon .
51. Click on the single circuit, here:
board_1
.
52. Click on the
Cluster Editor
option on the
SERVICES
menu.
The Cluster Editor is opened.
53. Click on the
Structure Editor
option on the
SERVICES
menu.
A file selection window is opened.
54. Select a PCB by double-clicking, here:
Example_2.la
.
The PCB Editor for Example_2.la is opened.
55. Click on the PCB (rectangle), here:
Example_2
.
56. Using the key combination Alt+Tab change to the Cluster Editor of the single circuit, here:
board_1
.
57. Click on the
Load cluster data from
option on the
EDIT
menu.
A dialog box containing the name of the source cluster is displayed.
58. Click on the
OK
button.
The cluster data of the other PCB, here:
Example_2
, are transferred to the current single circuit, here:
board_1
, the dialog box is closed. The Placement Position Editor is opened.
59. Using the key combination Alt+Tab change to the PCB Editor of the other PCB, here:
Example_2.la
.
60. Click on the PCB, here:
Example_2.la
.
61. Using the key combination Alt+Tab change to the Placement Position Editor of the single circuit, here:
board_1
.
62. Click on the
Load placement position from
option on the
EDIT
menu.
A dialog box containing the name of the source cluster is displayed.
63. Click on the
OK
button.
The placement positions of the other PCB, here:
Example_2
, are transferred to the single circuit, here:
board_1
, the dialog box is closed.
64. Click on the
Quit
option on the
FILE
menu.
The Placement Position Editor is closed.
