. User’s Manual Line Computer UNIX
18.3 Index Software Version 403.xx Edition 06/97
18 - 12
User’s Manual Line Computer UNIX
Software Version 403.xx Edition 06/97
Restriction Relating to the Use of "Mixed Lines"
NOTE
When using
"mixed lines"
(see Table), please keep in mind that the new Optimization feature designed to cal-
culate the placement sequence (see chapt. 11, section 11.2) cannot be used.
Annotation: The placement sequence is defined in the PP-Editor (see chapt. 8, section 8.1.6.3) by assigning
the placement positions to the different levels.
Example of a "mixed line":
Line Components Software Version
Line computer 403.01 (403.02)
SIPLACE S20 402.04
SIPLACE F
4
402.04
SIPLACE F4/6 403.01 (403.02)
