3 Desktop (Root Window) User’s Manual Line Computer UNIX

3.2 Desktop User Interface Software Version 403.xx Edition 06/97

3 - 22

Icon

Errors

= Error Signalling System User Interface (see chapt. 15)

The error messages are classified into informative messages for the observation of the system, error

messages not entailing any danger for the overall system, and warning messages. Depending on the

individual requirements of the user, he can select from the different message types the message he

needs and can have this message displayed on the user interface of the error signalling system.

3.2.3 Line Selection Button and Display Area

3.2.3.1 Line Selection Button

Above the view area the line selection button is located indicating the designation of the current line (see Fig.

3.1.1). If the button is clicked on, a new line can be selected, provided several lines were configured upon

installation

Selection of a new line

●

Click on the Line Selection button.

The FSB for the selection of a new line (see example below) is opened.

●

Select <Name>

.ak

of the desired line by double-clicking.

The FSB is closed. The most recently displayed line is deleted from the display area, and the

stations of the newly selected line are displayed symbolically in the display area after a few

moments.

User’s Manual Line Computer UNIX 3 Desktop (Root Window)

Software Version 403.xx Edition 06/97 3.2 Desktop User Interface

3 - 23

3.2.3.2 View Area

Here, all stations that were entered for a line during the line configuration (see chapt. 12, section 12.2) are

represented by type-specific icons. Every station symbol is identified by the name that was entered for the

respective station during station configuration (see chapt. 12, section 12.1). As a rule, the currently used line

is displayed. Each station represented in the display area is provided with

sensitive

areas (see Fig. 3.1.2).

These areas have been assigned functions which can be activated by clicking the mouse.

Feeder Part

If an area of a station is clicked on that represents a given feeder part of that station (see Fig. 3.1.2), first

an FSB containing the names of all already-defined set-ups is opened. After selecting or entering a set-

up name, the user interface of the Set-Up Editor for the respective station, containing the display of the

selected feeder part, is opened (see chapt. 13).

The set-up of a station can be described by means of the Set-Up Editor.

Symbol

Clicking on the area of a station containing the "i" symbol (see Fig. 3.1.2) causes the user interface of

the respective station controller to be opened (see chapt. 14).

The user is provided with the possibility to inform himself of the state of a given station via the

respective station controller. Information about the operating mode, the current lot and the current

PCB, the station configuration and station messages is displayed.

Bar Chart Symbol

If the area containing the bar chart symbol is clicked on at a station (see Fig. 3.1.2), the MaDaMaS

evaluation screen opens (see chapt. 16).

In the case of an adhesive application station, the "Distribution of events" evaluation type is displayed,

in the case of a placement station, the "Track information" evaluation type.

3.2.4 Main Menu

The main menu is opened by clicking on the right border of the screen holding down the left mouse button.

For structure and operation of the main menu refer to chapt. 2 of this manual.

NOTE

The main menu is only used for special procedures in the event of problems in the LC program, following

any changes made to system settings, and for the

Shut Down

process of the computer system!
