Bestprolingcapability
for reproducible procedures
Through the use of innovative control, blower, heating and
sensor components combined with a solid machine design,
Rehm supplies a high-quality system enabling you to run and
log stable processes in your production operations.
Our application specialists will be pleased to help you dene
the optimum setting parameters for your sub-assembly pro-
duction. In-house training courses and process and mainte-
nance training courses in your production environment round
off the services offered by Rehm Thermal Systems.
Our Alteco is easily accessible for minimum
maintenance effort. The system cladding and the
doors of the process towers can be opened. The
electronic switching cabinet at the back of the
system with EMC-compliant, transparent design
and a separate performance/control part is also
freely accessible. The heat exchangers of the
cooling tract can be replaced quickly and conven-
iently.
Easy maintenance
Stable temperature prole
Freely accessible switching cabinet Easy maintenance of the heat
exchangers in the cooling tract
t
°C
100
50
zone 1–4 zone 5–8
500 s 1000 s 1500 s 2000 s
0
Flexible loading
Goods carrier with flexible width setting to ac-
commodate circuit boards with different transport
widths
Vertical stacking principle in the process towers for
receiving the goods carriers
Segmented cooling tract with automatic width
adjustment for each zone for the processing of
different circuit board sizes
Alteco with automatic product carrier adjust-
ment allows simultaneous drying of two different
painted boards within a single system. Different
sizes, e.g. from two paint lines, can be conveyed
to the oven in no particular order. The product
carrier width is automatically set to the width of
the product. This means that several production
lines with different products can be covered by
one vertical stove.
Alteco lets goods be stacked on the product car-
rier form and force-locked without using chains.
No lubricant is therefore needed in the transport
system. The risk of steaming the assemblies with
oil mist is completely eliminated.
Alteco’s downstream cooling section ensures the
best assembly cooling. This is a cascaded, 3-part
cooling section. Depending on the product range,
the transport units are prepared including the
downstream cooling section. This enables seam-
less product change. The vertical dryer or cooling
section does not need emptying.
Vertical stacking principle
Segmented cooling tract
