7OM-1603 2-32 Chapter 2 : 3. Product Change Menu [6] [Move & Adjust] Button When this button is pressed, the recognition window appears and the manual alignment operation is enabled. [7] [OK], [CANCEL] Button Using t…
7OM-1603
Chapter 2 : 3. Product Change Menu
2-31
3.2.2 "Tray PU Pos Tch" Window
This window can be used to Perform a teaching operation to determine the feeder
(B) offset for the tray components.
[2]
[1]
[4]
[5]
[6]
[7]
[9]
[8]
[3]
"Tray PU Pos Tch" window F7B26
[1] Feeder No. Tray Set Display
The Feeder No., where the components are picked up, magazine, setup and
blocks are displayed in this pane.
[2] [Tray Select] Button
The tray to be taught is selected in this data box.
[3] [Draw] Button
When this button is pressed, the tray selected in [2] is drawn out from the
elevator unit.
[4] Matrix
The matrix to be taught is set in this group box.
[5] Teach Mode
The following two types of teaching methods are provided and should be
selected according to the component size.
Teaching Operation with the [Center] Button
Normally, using this button, the component center is aligned with the screen
center and so the teaching operation is performed.
Teaching Operation with the [Corner1] and [Corner2] Buttons
When a component is large in size, these keys are used to align two points on
the component and a teaching operation is performed based on the alignment.
1102-003
Graphic
Development
7OM-1603
2-32
Chapter 2 : 3. Product Change Menu
[6] [Move & Adjust] Button
When this button is pressed, the recognition window appears and the manual
alignment operation is enabled.
[7] [OK], [CANCEL] Button
Using these buttons, the set parameters are reected on the machine
operation or cancelled.
[8] [Storage] Button
When this button is pressed, the tray drawn out in [3] is stored.
[9] Feeder (B) Offset
Displayed are the current values that indicate the pickup position. After a
teaching operation is performed, the results appear in the text boxes entitled
"Adj".
Before
: Values before Teaching Operation
After
: Results of Teaching Operation
1102-003
7OM-1603
Chapter 2 : 3. Product Change Menu
2-33
3.2.3 "PU Pos Ofst Tch" Window
[2]
[1]
[3]
[4]
[5]
[6]
[8]
[7]
"PU Pos Ofst Tch" window F7B27
[1] Feeder No. Tray Set Display
The Feeder No. where the components are picked up, magazine, setup, block
and head are displayed in this pane.
[2] [Fdr Select] Button
When this button is pressed, the feeder to be taught is selected.
[3] [Draw] Button
When the multi-layer tray feeder has been selected in [2], using this button,
the tray is drawn out from the elevator unit.
[4] Matrix
The matrix to be taught is set in this group box.
[5] [Move & Adjust] Button
When this button is pressed, the recognition window appears and the manual
alignment operation is enabled.
[6] [OK], [CANCEL] Button
Using these buttons, the set parameters are reected on the machine
operation or cancelled.
[7] [Storage] Button
The tray drawn out in [3] is stored.
[8] Feeder (B) Offset
Displayed are the current values that indicate the pickup position. After a
teaching operation is performed, the results appear in the text boxes entitled
"Adj".
Before
: Values before Teaching Operation
After
: Results of Teaching Operation
