7OM-1603 Chapter 4 : 2. Maintenance Check List 4-9 2.4 Quarterly Maintenance Note DE1 : DAPHNE EPONEX GREASE No. 1 NM1 : MOL YNOC GREASE AP1 Object Units Inspection, Cleaning, and Lubrication Spots Work Grease Required I…
7OM-1603
4-8
Chapter 4 : 2. Maintenance Check List
2. Maintenance Check List
The periodic maintenance items (inspection, cleaning, lubrication, etc.) are
classied and described based on how frequently each item should be performed.
Use the tables below as check lists.
Reference
Refer to "3. Maintenance Spots" for the spots to be maintained.
2.1 Daily Maintenance
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Items Check
3.2.5
Traverse Cart
Upper Surface of Feeder
Base
Cleaning - Vacuum Cleaner, Rag
Scrap Box Cleaning - -
Reel Box Cleaning - Vacuum Cleaner
T7D6
2.2 Weekly Maintenance
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Items Check
3.2.5
Traverse Cart
Groove on Feeder Base Cleaning ----- Vacuum Cleaner
3.2.5.1
Cutter Unit
Cutter Box Inside Cleaning - Vacuum Cleaner
Flat Ring Cleaning
T7D7
2.3 Monthly Maintenance
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Items Check
3.2.1
Pallet
Pallet Inspection
and
Cleaning
- Rag and Visual
Inspection
T7D8
1109-004
7OM-1603
Chapter 4 : 2. Maintenance Check List
4-9
2.4 Quarterly Maintenance
Note
DE1
: DAPHNE EPONEX GREASE No. 1
NM1
: MOLYNOC GREASE AP1
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Items Check
3.2.1
Pallet
Rails Inspection - Scale
Upper Surface Inspection - Scale
3.2.2
Elevator Unit
Ball Screw Lubrication DE1 Oiled Rag and Brush
Frame Lower Surface Inspection
and
Cleaning
Rag
Linear Guide Lubrication DE1 Oiled Rag, Brush and
Hand Grease Gun
Belt Inspection - Visual Inspection
3.2.3
Magazine Base
Cylinder Connection
Sections
Lubrication NM1 Oiled Rag, Syringe and
Nozzle (No.18)
3.2.4
Magazine
Rack Shutter Fulcrum
Section
Lubrication NM1 Oiled Rag, Syringe and
Nozzle (No.18)
3.2.5
Traverse Cart
Pallet Receiver Inspection - Visual Inspection
Linear Guide Lubrication DE1 Oiled Rag
Pallet Chuck Lubrication DE1 Oiled Rag
3.2.5.1
Cutter Unit
Linear Guide Lubrication DE1
T7D9
1109-003
7OM-1603
4-10
Chapter 4 : 2. Maintenance Check List
2.5 Yearly Maintenance
Note
DE1
: DAPHNE EPONEX GREASE No. 1
NM1
: MOLYNOC GREASE AP1
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Items Check
3.2.2
Elevator Unit
Elevator Clamp Rod Inspection - Visual Inspection
3.2.3
Magazine Base
Magazine Rail Lubrication DE1 Oiled Rag, Syringe and
Nozzle (No.18)
3.2.5
Traverse Cart
Elevator Clamper Lubrication NM1 Oiled Rag, Syringe and
Nozzle (No.18)
Positioning Pin Lubrication NM1 Oiled Rag, Syringe and
Nozzle (No.18)
3.2.5.1
Cutter Unit
Fluorine Sheet
Replacement
- Screwdriver, Wrench
Urethane Clamp
Replacement
- Screwdriver, Wrench
Flat Ring
Replacement
-
T7D10
