Safe-4 Safety Precautions 7OM-1603 3. Common Precautionary Items 1 109-004 Notes on Machine Operation Please keep the instruction manual in a safe place within reach. Follow the instructions in the instruction manual…
Safe-3
Safety Precautions
7OM-1603
3. Common Precautionary Items
1109-004
3. Common Precautionary Items
Precautions before Use
Only a well-trained person should operate the machine.
Do not allow any untrained person to operate the machine.
Mishandling of the machine can cause a serious accident.
Before operating the machine, please read the instruction manual carefully for correct
operations.
Although the precautionary items have been reviewed repeatedly, an incident far
beyond our expectation may occur.
Not only follow the precautionary instructions described in the instruction manual but
also try to handle the machine carefully at your discretion all the time.
Conrm that no covers are disengaged before operating the machine.
If the machine is used with its cover(s) being detached, a serious accident may occur.
Be sure to attach the covers if they are disengaged.
Make certain that no people or objects come in contact with the moving mechanisms
of the machine (SIGMA-G4/G5).
Then, check safety and power up the machine to start operation.
Do not start the machine unless those working in the immediate area of the machine
are aware of hazards from moving parts.
Do not bring the tray magnet close to the area where a pacemaker is implanted.
Otherwise, the pacemaker may be inuenced by electromagnetic impulses of the
magnet, causing the wearer to faint, etc.
In principle, the overall operation of the machine including the button
operations on the operation panel of the machine (SIGMA-G4/G5) and the
touch screen must be controlled by only one person.
If operated by more than one, ensure good communication by giving loud verbal
instructions to avoid any danger that might be caused by an unexpected movement of
the machine.
Before starting the automatic operation, check carefully that there is no person around
the machine (especially on the other side of the machine operation). Make sure that no
objects (tools, parts, etc.) are left behind.
Be sure to strictly keep the above-mentioned instructions. Otherwise, not only wrong
operations of the machine but also personal injury will result.
Safe-4
Safety Precautions
7OM-1603
3. Common Precautionary Items
1109-004
Notes on Machine Operation
Please keep the instruction manual in a safe place within reach.
Follow the instructions in the instruction manual for correct handling of the machine.
Be sure to fully understand the contents of the safety instructions in the instruction
manual and follow the instructions.
Please pay special attention to the precautionary items labeled on the machine or
described in the instruction manual and be sure to keep them. When the precautionary
items are ignored, it will result in personal injury or property damage (damage to the
machine).
Be sure to follow the operational instructions described in the instruction manual.
Do not modify the machine nor use any parts other than the specied ones for the
machine. Be sure not to use the machine with its safety devices detached. Doing
otherwise may cause personal injury.
Do not perform any operations other than those described in the instruction manual.
Whenever a problem arises, regarding the machine operations, performance, etc.,
please contact the marketing department or sales agency of Hitachi High-Technologies
for the solution.
This machine uses energetic driving systems and high voltage to run at high
speed. This power and voltage are high enough to cause a serious injury.
To avoid this danger, respect the following guideline.
Operate the machine with the covers being attached.
Before operating the machine be sure to close the magazine door.
Do not disengage the interlock mechanisms of the magazine door.
After performing setup operations with the magazine door being open, be
sure to close it securely.
Whenever you feel danger or abnormality, immediately press the
[EMERGENCY STOP] switch of the machine (SIGMA-G4/G5) to stop the
machine.
If the machine is kept running in abnormal condition, an accident or a
breakdown will result.
Safe-5
Safety Precautions
7OM-1603
3. Common Precautionary Items
When there is a problem with the machine (SIGMA-G4/G5), locate the cause
and assess the condition. Set the power breaker to "OFF".
Aftertheproblemhasbeenrectiedcompletely,resetthemachinetoits
normal condition.
When the tower light (green) of the machine (SIGMA-G4/G5) is ON or ashing, it
indicates that the static machine is in the "Automatic" mode (standby mode).
In case of a disaster of any kind, earthquake, storm, ood, re, or lightning,
immediately stop the machine (SIGMA-G4/G5) and turn off the power supply.
When the machine (SIGMA-G4/G5) stops due to a component pickup error, be sure to
remove the miss-picked component from the feeder and start the automatic operation.
1109-004
