Safe-13 Safety Precautions 7OM-1603 5. Alert Labels 1 109-005  T raverse Cart (10) (1 1) (16) (4) A W ARNING Moving Mechanisms! WARNING Moving Mechanisms! CAUTION Pay attention to the moving mechanisms! Do not put your …

100%1 / 195
Safe-12
Safety Precautions
7OM-1603
5. Alert Labels
1109-002
Magazine
(15)
kg
(17)
kg
Safe-13
Safety Precautions
7OM-1603
5. Alert Labels
1109-005
Traverse Cart
(10)
(11)
(16)
(4)
A
WARNING
Moving Mechanisms!
WARNING
Moving Mechanisms!
CAUTION
Pay attention to the moving
mechanisms!
Do not put your hand in the moving area.
Otherwise, your
h and
might be caught in
the moving area and injured.
CAUTION
Pay attention to the moving
mechanisms!
Do not put your hand in the moving area.
Otherwise, your
hand
might be caught in
the moving area and injured.
(9)
(8)
(14)
Before setting up the recycle conveyor,
open the feeder incorrect setup
preventive cover.
Before setting up the recycle conveyor,
open the feeder incorrect setup
preventive cover.
Avoid dropping a feeder!
It is heavy and if dropped, an injury will result.
Hold the grip during the work.
Cutter Unit
(12)
(13)
View A
Avoid dropping a cutter!
It is heavy and if dropped, an injury will result.
Remove or attach the cutter unit with the
handle securely held.
Avoid dropping a cutter!
It is heavy and if dropped, an injury will result.
Remove or attach the cutter unit with the
handle securely held.
Be careful with the cutter
blade. Otherwise, your finger
might be cut and injured.
Do not touch the cutter blade.
Only service personnel who has completed
the maintenance training course for the
cutter blade replacement, shall replace
the cutter blade.
Be careful with the cutter
blade. Otherwise, your finger
might be cut and injured.
Do not touch the cutter blade.
Only service personnel who has completed
the maintenance training course for the
cutter blade replacement, shall replace
the cutter blade.
Safe-14
Safety Precautions
7OM-1603
Alert Labels and Description
No. Alert Labels and Description
(1)
Description
This label indicates that high voltage is applied.
Do not touch the labeled areas. Otherwise, you will be given an electrical shock.
(2)
WARNING
Otherwise, an injury will result due
to breakage of the machine.
10-0061-
Stepping on Machine
Prohibited!
Description
Do not step on the machine. The machine may be damaged, causing you to fall
down from the machine and get injured.
(3)
WARNING
Trained Personnel Only!
Electric Shock or Hazardous Area
10-0015-
Description
Only the person who has nished operator training in the operation and
maintenance of the machine should touch the machine. Otherwise, any person other
than the trained one will be given an electrical shock or suffer an injury or a serious
accident.
1-1
1-2
DANGER
High Voltage Area!
Avoid electric shock.
10-0009-
00-0012-
1109-002
5. Alert Labels
